AirTAC ESV300-BASE · ISO Valve Base

Airtac ESV-M Base ESV302MB

Genuine AirTAC iso valve base, order code ESV302MB from the ESV300-BASE range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • PartManifold base (2M)
  • Ports and pilotBottom ports (B) · independent pilot
  • Port threadPT
  • PartsSingle base (1M), Manifold base (2M), End plate set (3M)
  • Working portsPT3/8
  • End-plate portsPT1/2
$31.39 $38.89Save 19%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every ESV300-BASE part, ports and pilot and port thread on one page All ESV300-BASE codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac ESV-M Base ESV302MB

The ESV302MB is the bottom-port variant of the AirTAC ESV300 manifold base (2M): its PT3/8 working ports sit under the base, so tubing drops vertically out of the valve plane instead of running along the left or right side. Any bottom port left unused is simply closed with a plug, which makes mixed station layouts easy to build.

Like every 2M base it bolts together with its neighbours into a manifold of any number of stations, one base per ESV3x0 solenoid or EAV3x0 air-piloted valve on the ISO 5599-1 face, and the whole assembly is capped by an ESV303M end plate set with PT1/2 supply and exhaust ports. The independent external pilot port at each station keeps externally piloted valves fed station by station.

Airtac ESV-M Base ESV302MB Technical Specifications

Order codeESV302MB
ProductISO Valve Base
PartManifold base (2M)
Ports and pilotBottom ports (B) · independent pilot
Port threadPT
PartsSingle base (1M), Manifold base (2M), End plate set (3M)
Working portsPT3/8
End-plate portsPT1/2
Mounting faceISO 5599-1
FluidAir (filtered by 40 µm element)
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C
Exhaust throttleBuilt in

Source: AirTAC Products Catalog 2026A (PDF01-P0094..P0096), ESV200/300/400/600 series specifications and ordering code.

How to choose

Compared with the plain ESV302M (left ports) and ESV302MR (right ports), this B variant trades side clearance for clean downward piping, the right choice when panels are shallow or tubing must leave through the sub-plate. If you would rather feed the pilot from the ESV303M end plate instead of independently per station, switch to the centralized-pilot ESV302MW; add the G suffix only if your piping is G (BSPP) rather than PT.

Applications

view_module

Tight electrical cabinets

Bottom-working ports let PT tubing exit through the sub-plate into the cabinet's cable channel, keeping the sides free for neighbouring valve stations and manual overrides.

precision_manufacturing

Pick-and-place gripper manifolds

A row of 2M bases with downward ports feeds short, direct lines to vertical cylinders, and the built-in exhaust throttle meters each station's exhaust with a hex key.

science

Independent-pilot test rigs

The per-station external pilot port lets each externally piloted valve be actuated separately while sharing one supply, handy for bench setups that change valve configurations often.

FAQ

What are the key figures of the ESV302MB?

Manifold base (2M), one per valve, ISO 5599-1 mounting face, PT3/8 working ports at the bottom (B) in PT thread, unused bottom ports closed with plugs, independent external pilot port per station, built-in exhaust throttle, 1.5 MPa (215 psi) proof pressure, -20 to +70 C.

How does the pilot port work on this base?

Each station has its own independent external pilot port, used only when the mounted ESV3x0 or EAV3x0 valve is externally piloted. If you prefer a single pilot feed for the whole manifold, choose the W variant ESV302MW, whose centralized pilot comes in through the ESV303M end plate.
