AirTAC ESV300-BASE · ISO Valve Base

Airtac ESV-M Base ESV302MGB

Genuine AirTAC iso valve base, order code ESV302MGB from the ESV300-BASE range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • PartManifold base (2M)
  • Ports and pilotBottom ports (B) · independent pilot
  • Port threadG (BSPP)
  • PartsSingle base (1M), Manifold base (2M), End plate set (3M)
  • Working portsPT3/8
  • End-plate portsPT1/2
$31.39 $38.89Save 19%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every ESV300-BASE part, ports and pilot and port thread on one page All ESV300-BASE codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac ESV-M Base ESV302MGB

In the AirTAC ESV300 ordering code, 2M identifies the manifold base: one base carries one ESV3x0 solenoid or EAV3x0 air-piloted valve on its ISO 5599-1 mounting face, and any number of bases bolt together into a bank. Working ports follow the series PT3/8 size, are threaded G (BSPP) on this version, and the B option places them on the bottom face.

Because the ports face down, supply and actuator lines approach from underneath, keeping the top and sides of the manifold clear. Each station keeps an independent external pilot port, and the built-in exhaust throttle is set with a hex key, clockwise to reduce exhaust flow, so no separate speed controller is required. Unused bottom ports are closed with plugs.

Airtac ESV-M Base ESV302MGB Technical Specifications

Order codeESV302MGB
ProductISO Valve Base
PartManifold base (2M)
Ports and pilotBottom ports (B) · independent pilot
Port threadG (BSPP)
PartsSingle base (1M), Manifold base (2M), End plate set (3M)
Working portsPT3/8
End-plate portsPT1/2
Mounting faceISO 5599-1
FluidAir (filtered by 40 µm element)
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C
Exhaust throttleBuilt in

Source: AirTAC Products Catalog 2026A (PDF01-P0094..P0096), ESV200/300/400/600 series specifications and ordering code.

How to choose

Pick ESV302MGB when the manifold sits on a surface and the piping enters from below. If the tubes must leave sideways, take ESV302MGR for right-hand ports; if you want one pilot feed for the whole bank, take the centralized-pilot ESV302MGW instead. A lone valve belongs on the single base ESV301MG, and every manifold is closed by one end plate set ESV303MG with its larger PT1/2 supply and exhaust ports.

Applications

valve

Bottom-piped valve bank

Mount ESV3x0 valves on the ISO 5599-1 face and bring G-thread supply and actuator lines up from below, one station per base.

tune

Per-station exhaust control

The built-in exhaust throttle on each base replaces a separate speed controller; turn the hex screw clockwise to slow the exhaust of any station.

factory

Dense machine layouts

With ports underneath and an independent pilot port per station, the sides of the manifold stay free for neighbouring components and tubing runs.

FAQ

What are the key figures of the ESV302MGB?

ISO 5599-1 mounting face for ESV3x0 and EAV3x0 valves; working ports in PT3/8 size, G (BSPP) thread, on the bottom face; proof pressure 1.5 MPa (215 psi); temperature -20 to +70 C; air filtered by a 40 um element; built-in exhaust throttle.

Why does the bottom-port option matter for the pilot port?

The B variant still gives every station an independent external pilot port, so each externally piloted valve is fed separately. Bottom working ports do not change this; only the W code would replace the individual pilot feeds with one centralized supply from the end plate.
