AirTAC ESV300-BASE · ISO Valve Base

Airtac ESV-M Base ESV302MGR

Genuine AirTAC iso valve base, order code ESV302MGR from the ESV300-BASE range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • PartManifold base (2M)
  • Ports and pilotRight ports (R) · independent pilot
  • Port threadG (BSPP)
  • PartsSingle base (1M), Manifold base (2M), End plate set (3M)
  • Working portsPT3/8
  • End-plate portsPT1/2
$31.39 $38.89Save 19%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every ESV300-BASE part, ports and pilot and port thread on one page All ESV300-BASE codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac ESV-M Base ESV302MGR

The R at the end of ESV302MGR fixes the piping direction: on this AirTAC ESV300 manifold base the PT3/8-size working ports leave to the right, cut as G (BSPP) thread. The base bolts side by side with its siblings and presents the ISO 5599-1 face for one ESV3x0 solenoid or EAV3x0 air-piloted valve per base.

Right-facing ports suit manifolds mounted with the opposite side against a wall or machine frame, where tubing can only exit toward the open side. Every station also gets an independent external pilot port, and the built-in exhaust throttle is adjusted with a hex key, clockwise to reduce exhaust flow, so no separate speed controller is needed.

Airtac ESV-M Base ESV302MGR Technical Specifications

Order codeESV302MGR
ProductISO Valve Base
PartManifold base (2M)
Ports and pilotRight ports (R) · independent pilot
Port threadG (BSPP)
PartsSingle base (1M), Manifold base (2M), End plate set (3M)
Working portsPT3/8
End-plate portsPT1/2
Mounting faceISO 5599-1
FluidAir (filtered by 40 µm element)
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C
Exhaust throttleBuilt in

Source: AirTAC Products Catalog 2026A (PDF01-P0094..P0096), ESV200/300/400/600 series specifications and ordering code.

How to choose

Between the three G-thread manifold bases, the choice is port direction and pilot scheme: ESV302MGR for right-hand ports, ESV302MGB for bottom ports, and the left-port, centralized-pilot ESV302MGW. R keeps an independent pilot port per station, so choose it over the W version when each externally piloted valve needs its own pilot feed. Single-valve duties use the ESV301MG base, and each bank ends with an ESV303MG end plate set.

Applications

conveyor_belt

Right-side tubing runs along conveyors

Mount the manifold beside the conveyor frame and route all G-thread actuator lines to the right, away from the belt mechanics.

cable

Stations fed by separate pilot lines

The independent pilot port per base lets each externally piloted EAV3x0 valve take its own pilot tube, so one station can be isolated without disturbing the others.

settings

Extending an existing bank

Because 2M bases bolt together, a right-port base can extend an ESV300 manifold wherever the free piping direction is to the right.

FAQ

What are the key figures of the ESV302MGR?

Working ports in PT3/8 size, G (BSPP) thread, exiting to the right; ISO 5599-1 mounting face for ESV3x0 and EAV3x0 valves; proof pressure 1.5 MPa (215 psi); temperature -20 to +70 C; air filtered by a 40 um element; built-in exhaust throttle adjusted with a hex key.

Does the R option change which valves fit the base?

No. R only sets the working-port direction. Any ESV3x0 solenoid or EAV3x0 air-piloted valve with the ISO 5599-1 face mounts the same way, and the independent external pilot port per station is retained.
