AirTAC ESV300-BASE · ISO Valve Base

Airtac ESV-M Base ESV302MGWB

Genuine AirTAC iso valve base, order code ESV302MGWB from the ESV300-BASE range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • PartManifold base (2M)
  • Ports and pilotBottom ports (B) · centralized pilot (W)
  • Port threadG (BSPP)
  • PartsSingle base (1M), Manifold base (2M), End plate set (3M)
  • Working portsPT3/8
  • End-plate portsPT1/2
$31.39 $38.89Save 19%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every ESV300-BASE part, ports and pilot and port thread on one page All ESV300-BASE codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac ESV-M Base ESV302MGWB

Manifold base (2M) of the ESV300 series, carrying one ESV3x0 or EAV3x0 valve on the ISO 5599-1 mounting face. This variant takes the 3/8 working ports to the bottom face in G (BSPP) thread, so actuator and supply lines drop straight down beneath the bank and stay clear of the valves mounted alongside.

The W in the order code means the external pilot port is centralized: a single pilot feed at the end plate serves every station, instead of an individual pilot port on each base. Each bank is closed with an end plate set (3M), whose supply and exhaust ports step up to PT1/2. Air must be filtered by a 40 um element, proof pressure is 1.5 MPa (215 psi), the temperature range is -20 to +70 C, and the exhaust throttle is built in.

Airtac ESV-M Base ESV302MGWB Technical Specifications

Order codeESV302MGWB
ProductISO Valve Base
PartManifold base (2M)
Ports and pilotBottom ports (B) · centralized pilot (W)
Port threadG (BSPP)
PartsSingle base (1M), Manifold base (2M), End plate set (3M)
Working portsPT3/8
End-plate portsPT1/2
Mounting faceISO 5599-1
FluidAir (filtered by 40 µm element)
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C
Exhaust throttleBuilt in

Source: AirTAC Products Catalog 2026A (PDF01-P0094..P0096), ESV200/300/400/600 series specifications and ordering code.

How to choose

Pick ESV302MGWB when piping must leave downward and the whole manifold shares one external pilot supply. If side-facing ports suit the layout better, order ESV302MGWR, which keeps the G thread and W pilot but moves the ports to the right. For per-station pilot control or standard PT threads, use ESV302MR. A single valve with no bank goes on the 1M single base instead, and every assembled manifold still needs one 3M end plate set.

Applications

packaging

Cartoning machines with tight side clearance

Bottom G-thread ports let tubing route vertically below the manifold, freeing the sides where guide rails and frames crowd the valve bank.

factory

Multi-station manifolds with one pilot feed

The centralized W pilot supplies all stations from a single connection at the end plate, simplifying externally piloted valve installations.

tune

Cylinder speed tuning without extra fittings

The built-in exhaust throttle is set with a hex key, clockwise to reduce exhaust flow, so no separate speed controller is needed on the ports.

FAQ

What are the key figures for the ESV302MGWB?

Manifold base (2M) with bottom 3/8 working ports in G (BSPP) thread and a centralized (W) external pilot fed from the end plate. Mounting face ISO 5599-1, proof pressure 1.5 MPa (215 psi), temperature -20 to +70 C, air filtered by a 40 um element, exhaust throttle built in.

How is the exhaust flow adjusted, and what happens to unused ports?

A throttle is built into each exhaust: turn the adjusting screw with a hex key, clockwise to reduce the exhaust flow. Unused bottom ports are closed with plugs.
