AirTAC ESV300-BASE · ISO Valve Base

Airtac ESV-M Base ESV302MR

Genuine AirTAC iso valve base, order code ESV302MR from the ESV300-BASE range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • PartManifold base (2M)
  • Ports and pilotRight ports (R) · independent pilot
  • Port threadPT
  • PartsSingle base (1M), Manifold base (2M), End plate set (3M)
  • Working portsPT3/8
  • End-plate portsPT1/2
$31.39 $38.89Save 19%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every ESV300-BASE part, ports and pilot and port thread on one page All ESV300-BASE codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac ESV-M Base ESV302MR

Right-hand working ports in standard PT thread make this the plain 2M manifold base of the ESV300 range: one ESV3x0 or EAV3x0 valve per base on the ISO 5599-1 face, 3/8 ports facing right, and no W in the code, so every station keeps its own independent external pilot port. That lets you feed, vent or service the pilot of one station without touching its neighbours.

Manifold bases bolt together into a bank of any size and are closed by an end plate set (3M), whose supply and exhaust ports are one size larger at PT1/2. Air must be filtered by a 40 um element, proof pressure is 1.5 MPa (215 psi) across a temperature range of -20 to +70 C, and each exhaust carries a built-in throttle adjusted with a hex key.

Airtac ESV-M Base ESV302MR Technical Specifications

Order codeESV302MR
ProductISO Valve Base
PartManifold base (2M)
Ports and pilotRight ports (R) · independent pilot
Port threadPT
PartsSingle base (1M), Manifold base (2M), End plate set (3M)
Working portsPT3/8
End-plate portsPT1/2
Mounting faceISO 5599-1
FluidAir (filtered by 40 µm element)
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C
Exhaust throttleBuilt in

Source: AirTAC Products Catalog 2026A (PDF01-P0094..P0096), ESV200/300/400/600 series specifications and ordering code.

How to choose

Choose ESV302MR when you want the standard PT thread and per-station pilot independence. The G-thread counterparts are ESV302MGWR for right ports and ESV302MGWB for bottom ports, both fitted with the centralized W pilot fed from the end plate. For a single valve outside a bank, the 1M single base is the alternative, and every assembled manifold still ends with a 3M end plate set.

Applications

valve

Directional control on PT-piped machinery

Standard PT threads match the piping conventions common on export and general-purpose machines, with 3/8 working ports facing right.

settings

Station-by-station maintenance access

The independent external pilot port on each base lets one station be isolated or serviced while the rest of the manifold keeps running.

straighten

Exhaust flow balancing across a bank

The built-in exhaust throttle on each base is turned clockwise with a hex key to reduce flow, tuning each cylinder individually.

FAQ

What are the key figures for the ESV302MR?

Manifold base (2M), right-side PT3/8 working ports, independent external pilot port per station, no centralized W option. Mounting face ISO 5599-1, proof pressure 1.5 MPa (215 psi), temperature -20 to +70 C, air filtered by a 40 um element, exhaust throttle built in.

How is a complete manifold assembled around this base?

Use one 2M base per valve, bolt the bases into a bank of any station count, and close the bank with one 3M end plate set, whose supply and exhaust ports are one size larger at PT1/2. Unused bottom ports are closed with plugs.
