AirTAC ESV300-BASE · ISO Valve Base

Airtac ESV-M Base ESV302MW

Genuine AirTAC iso valve base, order code ESV302MW from the ESV300-BASE range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • PartManifold base (2M)
  • Ports and pilotLeft ports · centralized pilot (W)
  • Port threadPT
  • PartsSingle base (1M), Manifold base (2M), End plate set (3M)
  • Working portsPT3/8
  • End-plate portsPT1/2
$31.39 $38.89Save 19%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every ESV300-BASE part, ports and pilot and port thread on one page All ESV300-BASE codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac ESV-M Base ESV302MW

The AirTAC ESV302MW is a 300 series manifold base (2M) built to the ISO 5599-1 mounting face: each base carries one ESV3x0 solenoid or EAV3x0 air-piloted valve, and several bases bolt together into a bank closed off by the ESV303M end plate set. Its working ports are PT3/8 on the left face, and the W in the order code marks a centralized external pilot port, so a single pilot feed at the end plate serves every station on the bank.

The base runs on air filtered by a 40 um element, takes a proof pressure of 1.5 MPa (215 psi), and works from -20 to +70 C. Each station has a built-in exhaust throttle: turn the adjusting screw with a hex key, clockwise to reduce exhaust flow, so no separate speed controller is needed.

Airtac ESV-M Base ESV302MW Technical Specifications

Order codeESV302MW
ProductISO Valve Base
PartManifold base (2M)
Ports and pilotLeft ports · centralized pilot (W)
Port threadPT
PartsSingle base (1M), Manifold base (2M), End plate set (3M)
Working portsPT3/8
End-plate portsPT1/2
Mounting faceISO 5599-1
FluidAir (filtered by 40 µm element)
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C
Exhaust throttleBuilt in

Source: AirTAC Products Catalog 2026A (PDF01-P0094..P0096), ESV200/300/400/600 series specifications and ordering code.

How to choose

Pick ESV302MW when piping should leave the left face of the bank and your externally piloted EAV3x0 valves can share one pilot supply. If each station needs an independent pilot connection, order the same base without the W code. Bottom and right routing is covered by ESV302MWB and ESV302MWR, a single-valve setup uses the ESV301M single base, and every manifold also requires one ESV303M end plate set.

Applications

valve

Manifold bank with one pilot feed

Bolt a row of ESV302MW bases onto a packaging machine, close the row with an ESV303M end plate set, and supply all externally piloted EAV3x0 valves from a single centralized pilot connection.

factory

Left-face hose routing

Install the bank along a machine wall where tubing must exit on the left side; the PT3/8 working ports keep hoses organized and clear of neighboring stations.

tune

Exhaust speed trimming

Set cylinder return speed station by station using the built-in exhaust throttle, turned clockwise with a hex key to reduce flow, without adding inline speed controllers.

FAQ

What are the key figures of the ESV302MW?

It is a 300 series manifold base (2M) with an ISO 5599-1 mounting face, PT3/8 working ports on the left face, a centralized external pilot port (W), proof pressure 1.5 MPa (215 psi), a -20 to +70 C temperature range, air filtered by a 40 um element, and a built-in exhaust throttle.

Which valves fit, and what does the centralized pilot do?

The base carries ESV3x0 solenoid and EAV3x0 air-piloted valves with the ISO 5599-1 face. The W option feeds the whole manifold from one pilot connection at the end plate, which simplifies piping for externally piloted valves; solenoid versions do not use the pilot port.
