AirTAC ESV300-BASE · ISO Valve Base

Airtac ESV-M Base ESV302MWB

Genuine AirTAC iso valve base, order code ESV302MWB from the ESV300-BASE range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • PartManifold base (2M)
  • Ports and pilotBottom ports (B) · centralized pilot (W)
  • Port threadPT
  • PartsSingle base (1M), Manifold base (2M), End plate set (3M)
  • Working portsPT3/8
  • End-plate portsPT1/2
$31.39 $38.89Save 19%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every ESV300-BASE part, ports and pilot and port thread on one page All ESV300-BASE codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac ESV-M Base ESV302MWB

In the AirTAC ESV300 series, the ESV302MWB manifold base (2M) mounts one ESV3x0 solenoid or EAV3x0 air-piloted valve on its ISO 5599-1 face and directs the PT3/8 working ports toward the bottom of the base. The B option sends tubing vertically below the bank, and any bottom port left unused is simply closed with a plug.

The base works on air filtered by a 40 um element, withstands a proof pressure of 1.5 MPa (215 psi) from -20 to +70 C, and has an exhaust throttle built into every station, adjusted with a hex key by turning the screw clockwise to reduce flow. Its W code marks a centralized external pilot port, fed once from the ESV303M end plate set instead of at each base.

Airtac ESV-M Base ESV302MWB Technical Specifications

Order codeESV302MWB
ProductISO Valve Base
PartManifold base (2M)
Ports and pilotBottom ports (B) · centralized pilot (W)
Port threadPT
PartsSingle base (1M), Manifold base (2M), End plate set (3M)
Working portsPT3/8
End-plate portsPT1/2
Mounting faceISO 5599-1
FluidAir (filtered by 40 µm element)
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C
Exhaust throttleBuilt in

Source: AirTAC Products Catalog 2026A (PDF01-P0094..P0096), ESV200/300/400/600 series specifications and ordering code.

How to choose

This is the bottom-port member of the centralized-pilot family: choose it over ESV302MW (left ports) and ESV302MWR (right ports) when air lines must drop straight down from the manifold. If your externally piloted valves need individual pilot feeds, order the base without W. Build the bank with one base per valve plus one ESV303M end plate set, or use the ESV301M single base for a lone valve.

Applications

settings

Downward drop piping

Mount the manifold above a machine bed or sub-panel and run PT3/8 hoses straight down from the bottom ports to actuators and fixtures below.

grid_view

Plugged spare stations

Pre-plumb a bank with future expansion in mind: keep unused bottom ports on ESV302MWB bases closed with plugs and add ESV3x0 or EAV3x0 valves as the line grows.

conveyor_belt

Conveyor line manifolds

Group the air-piloted valves controlling diverters and stops onto one ESV302MWB manifold, sharing a single centralized pilot supply from the end plate set.

FAQ

What are the key figures of the ESV302MWB?

Manifold base (2M), ISO 5599-1 mounting face, PT3/8 working ports on the bottom (B), centralized external pilot port (W), proof pressure 1.5 MPa (215 psi), temperature -20 to +70 C, air filtered by a 40 um element, built-in exhaust throttle at each station.

What happens to unused bottom ports?

Unused bottom ports are closed with plugs. Since the 2M manifold base serves one valve per base, you can leave plug positions free on bases reserved for valves that will be added later.
