AirTAC ESV300-BASE · ISO Valve Base

Airtac ESV-M Base ESV302MWR

Genuine AirTAC iso valve base, order code ESV302MWR from the ESV300-BASE range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • PartManifold base (2M)
  • Ports and pilotRight ports (R) · centralized pilot (W)
  • Port threadPT
  • PartsSingle base (1M), Manifold base (2M), End plate set (3M)
  • Working portsPT3/8
  • End-plate portsPT1/2
$31.39 $38.89Save 19%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every ESV300-BASE part, ports and pilot and port thread on one page All ESV300-BASE codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac ESV-M Base ESV302MWR

Order the AirTAC ESV302MWR when the manifold bank should exhaust its PT3/8 working ports from the right face: the R code mirrors the left-port layout, keeping hose runs on the side you choose. One base carries one ESV3x0 solenoid or EAV3x0 air-piloted valve on the ISO 5599-1 mounting face, and the 2M bases bolt together into a bank terminated by the ESV303M end plate set.

Air, filtered by a 40 um element, is the only fluid, and the base is rated for a 1.5 MPa (215 psi) proof pressure across -20 to +70 C. Each station integrates an exhaust throttle set by a hex key, clockwise to reduce exhaust flow. The W code means the external pilot port is centralized: one pilot feed at the end plate, whose supply and exhaust ports are one size larger at PT1/2, serves the entire manifold.

Airtac ESV-M Base ESV302MWR Technical Specifications

Order codeESV302MWR
ProductISO Valve Base
PartManifold base (2M)
Ports and pilotRight ports (R) · centralized pilot (W)
Port threadPT
PartsSingle base (1M), Manifold base (2M), End plate set (3M)
Working portsPT3/8
End-plate portsPT1/2
Mounting faceISO 5599-1
FluidAir (filtered by 40 µm element)
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C
Exhaust throttleBuilt in

Source: AirTAC Products Catalog 2026A (PDF01-P0094..P0096), ESV200/300/400/600 series specifications and ordering code.

How to choose

Choose ESV302MWR over ESV302MW (left ports) and ESV302MWB (bottom ports) when piping exits on the right of the bank, for example toward a valve compartment on that side. The W centralized pilot suits externally piloted EAV3x0 valves; drop the W if each station must take its own pilot feed. For a single valve, compare the ESV301M single base, and always add one ESV303M end plate set per manifold.

Applications

packaging

Right-edge piping on packing lines

Position the manifold at the right end of a packaging machine so the PT3/8 hoses to grippers and clamps exit on the right face, away from the operator side.

sync

Shared pilot on air-piloted banks

Run EAV3x0 externally piloted valves on a multi-station bank fed by one centralized pilot supply from the ESV303M end plate, instead of piping a pilot line to every base.

check_circle

Uniform station layout

Standardize on right-port ESV302MWR bases so replacement valves and spare bases keep the same hose orientation across every machine in the plant.

FAQ

What are the key figures of the ESV302MWR?

It is a manifold base (2M) in the 300 series with an ISO 5599-1 mounting face, PT3/8 working ports on the right face (R), centralized external pilot (W), proof pressure 1.5 MPa (215 psi), operating range -20 to +70 C, 40 um filtered air, and a built-in exhaust throttle per station.

How is the centralized pilot supplied on this base?

With the W option, one pilot feed enters at the ESV303M end plate set, whose supply and exhaust ports are PT1/2, and is distributed to every station on the manifold. An independent pilot port per station is obtained by ordering the base without the W code.
