Genuine AirTAC iso valve base, order code ESV401M from the ESV400-BASE range. The options this code selects are decoded below; series data follow the official AirTAC catalog.
The ESV401M is the single base (suffix 1M) of the AirTAC ESV400 series: it carries exactly one valve with the ISO 5599-1 mounting face, either an ESV4x0 solenoid valve or an EAV4x0 air-piloted valve, and presents the working ports at PT1/2 on the side. Because it is a standalone base rather than a manifold station, its external pilot port is independent, feeding the valve on this base separately.
Exhaust control is built in. A hex key turned on the adjusting screw changes the exhaust throttle - clockwise reduces the exhaust flow - so cylinder speed can be set at the base without adding a separate speed controller. The base works on air filtered by a 40 um element, takes 1.5 MPa (215 psi) proof pressure and covers -20 to +70 C.
| Order code | ESV401M |
|---|---|
| Product | ISO Valve Base |
| Part | Single base (1M) |
| Ports and pilot | Side ports |
| Port thread | PT |
| Parts | Single base (1M), Manifold base (2M), End plate set (3M) |
|---|---|
| Working ports | PT1/2 |
| End-plate ports | PT3/4 |
| Mounting face | ISO 5599-1 |
| Fluid | Air (filtered by 40 µm element) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature | -20 to +70 °C |
| Exhaust throttle | Built in |
Source: AirTAC Products Catalog 2026A (PDF01-P0094..P0096), ESV200/300/400/600 series specifications and ordering code.
Choose the ESV401M over the ESV401MB when you want the PT1/2 working ports on the side of the base, for example to run pipes horizontally along a panel. Choose it over an ESV402M manifold base plus ESV403M end plate set when only one valve is needed and future expansion into a multi-station bank is not planned. PT thread is standard on this code; for G parallel piping, order the same single base with the G suffix instead.
Machine points that need one direction or one function - a single clamp, ejector or chute gate - get their ESV4x0 or EAV4x0 valve a proper ISO 5599-1 seat with PT1/2 side ports.
For an externally piloted valve, the ESV401M has its own independent external pilot port, so the pilot signal to this one valve can be run and adjusted separately from any other circuit.
Swapping ISO 5599-1 valves on a single base during trials is quick: unbolt one valve, seat the next, and use the built-in exhaust throttle to retune cylinder speed without extra fittings.
Single base (1M) for one ISO 5599-1 valve, PT1/2 side working ports, an independent external pilot port, a built-in exhaust throttle adjusted with a hex key (clockwise reduces exhaust flow), 1.5 MPa (215 psi) proof pressure, -20 to +70 C, and air filtered by a 40 um element.
Any ESV400-series valve with the ISO 5599-1 mounting face: ESV4x0 solenoid valves and EAV4x0 air-piloted valves. The independent external pilot port matters only when you fit an externally piloted valve - it feeds this single base separately, which is one reason a standalone base differs from a manifold station.
