Airtac GTFR Filter Regulator GTFR20006L
Genuine AirTAC filter regulator, order code GTFR20006L from the GTFR200 range. The options this code selects are decoded below; series data follow the official AirTAC catalog.
- Port1/8" (06)
- Type · gaugeLow-pressure (L) · With gauge (MPa/psi)
- ConfigurationWith bracket · 40 µm element · PT thread
- Port1/8" (06), 1/4" (08)
- ThreadPT (standard)
- Filter element40 µm (standard), 5 µm (W)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GTFR Filter Regulator GTFR20006L
The GTFR20006L is the low-pressure, fully equipped version of the AirTAC GTFR200 filter regulator. Its L suffix sets a regulated range of 0.15 to 0.4 MPa (20 to 58 psi), well below the standard type, and the 06 body gives a 1/8 in PT port. Air passes through the standard 40 um element into a short PC bowl, where condensate is removed by the differential plus manual drain, and the compact GT200 footprint suits machines where a full-size GA200 unit will not fit.
This code carries no J, N, W, G or T suffixes, so everything standard stays on board: the pressure gauge (reading MPa/psi) is fitted, the mounting bracket is included, the element is 40 um, and the threads are PT. You only need a regulator and a line fitting to put it to work.
Airtac GTFR Filter Regulator GTFR20006L Technical Specifications
| Order code | GTFR20006L |
|---|---|
| Product | Filter Regulator |
| Port | 1/8" (06) |
| Type · gauge | Low-pressure (L) · With gauge (MPa/psi) |
| Configuration | With bracket · 40 µm element · PT thread |
| Port | 1/8" (06), 1/4" (08) |
|---|---|
| Thread | PT (standard) |
| Filter element | 40 µm (standard), 5 µm (W) |
| Bowl | Short PC bowl |
| Drain | Differential + manual |
| Fluid | Air |
| Low-pressure (L) version | 0.15 – 0.4 MPa (20 – 58 psi) |
Source: AirTAC Products Catalog 2026A (p.235, PDF01-P0237), GT200 ordering code and specifications.
How to choose
Choose GTFR20006L when your line is 1/8 in and your process runs at low pressure. If your circuit must hold its downstream setting when upstream air is shut off, step up to GTFR20006LJK, which adds a check valve. For cleaner air, order the W variant with the 5 um element instead of the standard 40 um. If you mount the unit on your own plate or panel, GTFR20006LJ omits the bracket, and GTFR20008L is the equivalent for a 1/4 in line. The standard-pressure GTFR20006S covers the normal range if 0.15 to 0.4 MPa is too low.
Applications
Low-pressure test rigs
Bench leak and functional test stations often need a stable supply far below normal line pressure; the L range of 0.15 to 0.4 MPa (20 to 58 psi) is set directly on the fitted gauge.
Gentle packaging air
Sealing, counting and conveying heads in packaging lines run on soft regulated air from a 1/8 in take-off, with the 40 um element protecting the downstream valves.
Panel-mounted fine tuning
The included bracket lets you fix the short PC bowl unit beside the machine, and the differential plus manual drain clears accumulated condensate during operator rounds.
FAQ
What are the key figures of the GTFR20006L?
Port: 1/8 in (06), PT thread standard. Type: low-pressure L, regulated range 0.15 to 0.4 MPa (20 to 58 psi). Element: 40 um standard. Bowl: short PC with differential plus manual drain. Gauge: included. Bracket: included. Fluid: air.
What does the L in the order code change?
L selects the low-pressure version of the GTFR200. Instead of the standard regulated range, it regulates 0.15 to 0.4 MPa (20 to 58 psi), which suits circuits that must never see full line pressure. Port, element and bowl behaviour stay as in the standard unit.
