Airtac GTFR Filter Regulator GTFR20006LJNW
Genuine AirTAC filter regulator, order code GTFR20006LJNW from the GTFR200 range. The options this code selects are decoded below; series data follow the official AirTAC catalog.
- Port1/8" (06)
- Type · gaugeLow-pressure (L) · No gauge (N)
- ConfigurationNo bracket (J) · 5 µm element (W) · PT thread
- Port1/8" (06), 1/4" (08)
- ThreadPT (standard)
- Filter element40 µm (standard), 5 µm (W)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GTFR Filter Regulator GTFR20006LJNW
The AirTAC GTFR20006LJNW is a GT200-series filter regulator whose W option replaces the standard 40 um element with a 5 um element, delivering noticeably cleaner air for sensitive downstream equipment. It is built on the 1/8 in (06) port with PT thread and the low-pressure L type, which regulates 0.15 - 0.4 MPa (20 - 58 psi) for circuits that never see full shop air pressure.
Like every GT200 unit it uses the short PC bowl, the compact short-bowl version of the GA200 body, with a differential plus manual drain. N deletes the gauge and J deletes the mounting bracket, so the code describes a bare, compact prep unit: fine filtration, low-pressure regulation and no accessories you did not ask for.
Airtac GTFR Filter Regulator GTFR20006LJNW Technical Specifications
| Order code | GTFR20006LJNW |
|---|---|
| Product | Filter Regulator |
| Port | 1/8" (06) |
| Type · gauge | Low-pressure (L) · No gauge (N) |
| Configuration | No bracket (J) · 5 µm element (W) · PT thread |
| Port | 1/8" (06), 1/4" (08) |
|---|---|
| Thread | PT (standard) |
| Filter element | 40 µm (standard), 5 µm (W) |
| Bowl | Short PC bowl |
| Drain | Differential + manual |
| Fluid | Air |
| Low-pressure (L) version | 0.15 – 0.4 MPa (20 – 58 psi) |
Source: AirTAC Products Catalog 2026A (p.235, PDF01-P0237), GT200 ordering code and specifications.
How to choose
The W letter is the deciding difference here: GTFR20006LJN uses the standard 40 um element, while this code filters down to 5 um, the right choice when pilots, instruments or small actuators need cleaner air. If you also need downstream retention on supply loss, the ordering table lists K (check valve) as a separate letter that can be specified alongside; otherwise GTFR20006LJNK covers that need with the 40 um element.
Applications
Instrument and sensor air
Supplying 0.15 - 0.4 MPa (20 - 58 psi) air to pneumatic instruments and sensors from a 1/8 in PT line, where the 5 um element removes finer particles than the standard 40 um element would.
Fine air for small actuators
Protecting small pilots and compact actuators that run at low pressure, since the 5 um W element keeps contaminant out of narrow internal passages.
Laboratory pneumatic circuits
Feeding bench-scale rigs that need both gentle low-pressure regulation and clean air, with the bare no-gauge, no-bracket configuration letting the lab add its own pressure indication.
FAQ
What are the key figures of GTFR20006LJNW?
Port 1/8 in (06) with PT thread; low-pressure L regulation of 0.15 - 0.4 MPa (20 - 58 psi); 5 um filter element (W); short PC bowl with differential plus manual drain; no gauge (N), no bracket (J) and no check valve.
Why choose the W element, and does it change anything else?
W swaps the standard 40 um element for a 5 um element, so the air delivered downstream is cleaner, which suits instruments and finely machined components. The pressure range stays at 0.15 - 0.4 MPa (20 - 58 psi) and the 1/8 in PT port, short PC bowl and drain arrangement are unchanged from the rest of the low-pressure 1/8 in family.
