Airtac GTFR Filter Regulator GTFR20006LN
Genuine AirTAC filter regulator, order code GTFR20006LN from the GTFR200 range. The options this code selects are decoded below; series data follow the official AirTAC catalog.
- Port1/8" (06)
- Type · gaugeLow-pressure (L) · No gauge (N)
- ConfigurationWith bracket · 40 µm element · PT thread
- Port1/8" (06), 1/4" (08)
- ThreadPT (standard)
- Filter element40 µm (standard), 5 µm (W)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GTFR Filter Regulator GTFR20006LN
The N in GTFR20006LN means no pressure gauge: this low-pressure AirTAC GT200 filter regulator regulates 0.15 - 0.4 MPa (20 - 58 psi) on 1/8 inch (06) PT ports without a gauge on the body, so it suits panels that already carry their own indicator or sensor. The standard 40 um element filters the air in the compact GT200 short-bowl body, the tightened derivative of GA200.
The PC bowl is drained by differential plus manual operation, and a mounting bracket is included because the code carries no J. With no K suffix, this build has no check valve, keeping the pneumatic path to the essentials.
Airtac GTFR Filter Regulator GTFR20006LN Technical Specifications
| Order code | GTFR20006LN |
|---|---|
| Product | Filter Regulator |
| Port | 1/8" (06) |
| Type · gauge | Low-pressure (L) · No gauge (N) |
| Configuration | With bracket · 40 µm element · PT thread |
| Port | 1/8" (06), 1/4" (08) |
|---|---|
| Thread | PT (standard) |
| Filter element | 40 µm (standard), 5 µm (W) |
| Bowl | Short PC bowl |
| Drain | Differential + manual |
| Fluid | Air |
| Low-pressure (L) version | 0.15 – 0.4 MPa (20 – 58 psi) |
Source: AirTAC Products Catalog 2026A (p.235, PDF01-P0237), GT200 ordering code and specifications.
How to choose
Pick GTFR20006LN when your cabinet already shows pressure elsewhere; add a fitted gauge by ordering GTFR20006L instead, or keep the gauge-free layout and gain a check valve with GTFR20006LNK. For a 1/4 inch line move to GTFR20008LN, and if you need set pressures beyond the L version's 0.4 MPa top end, the standard S type is the variant to select.
Applications
Panels with external indication
Control cabinets that already read pressure through their own gauge or transmitter, where the N-coded gaugeless head avoids a duplicated indicator on the regulator.
Low-pressure actuator feeds
Light clamping, blowing and ejecting circuits specified in the 0.15 - 0.4 MPa (20 - 58 psi) range on a 1/8 inch (06) PT air line.
Compact panel installs
Shallow enclosures where the GT200 short PC bowl format and the included mounting bracket let the unit sit close to the panel wall without sacrificing the GA200 feature set.
FAQ
What are the key figures of the GTFR20006LN in one place?
Port 1/8 inch (06), PT thread, low-pressure range 0.15 - 0.4 MPa (20 - 58 psi), 40 um filter element, short PC bowl with differential and manual drain, mounting bracket included, no gauge (N) and no check valve. Fluid is air.
Do I need to add anything because the N code removes the gauge?
Yes: plan for an external gauge or use your panel's own sensor, since this regulator is delivered without one. GTFR20006L is the identical low-pressure unit with a gauge fitted if you would rather have the indication on the body.
