Airtac GTFR Filter Regulator GTFR20006LNK
Genuine AirTAC filter regulator, order code GTFR20006LNK from the GTFR200 range. The options this code selects are decoded below; series data follow the official AirTAC catalog.
- Port1/8" (06)
- Type · gaugeLow-pressure (L) · No gauge (N)
- ConfigurationWith bracket · 40 µm element · PT thread · Check valve (K)
- Port1/8" (06), 1/4" (08)
- ThreadPT (standard)
- Filter element40 µm (standard), 5 µm (W)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GTFR Filter Regulator GTFR20006LNK
GTFR20006LNK pairs two option letters on the low-pressure AirTAC GT200 filter regulator: N, which removes the pressure gauge, and K, which adds a check valve. Regulation stays within the 0.15 - 0.4 MPa (20 - 58 psi) band through 1/8 inch (06) PT ports, with the standard 40 um filter element doing the air cleaning.
The body is the compact GT200 short PC bowl, the tighter derivative of GA200, drained by differential plus manual operation, and a mounting bracket is included since the code omits J. Because no gauge is fitted, downstream setpoints have to be read by an instrument elsewhere in your panel.
Airtac GTFR Filter Regulator GTFR20006LNK Technical Specifications
| Order code | GTFR20006LNK |
|---|---|
| Product | Filter Regulator |
| Port | 1/8" (06) |
| Type · gauge | Low-pressure (L) · No gauge (N) |
| Configuration | With bracket · 40 µm element · PT thread · Check valve (K) |
| Port | 1/8" (06), 1/4" (08) |
|---|---|
| Thread | PT (standard) |
| Filter element | 40 µm (standard), 5 µm (W) |
| Bowl | Short PC bowl |
| Drain | Differential + manual |
| Fluid | Air |
| Low-pressure (L) version | 0.15 – 0.4 MPa (20 – 58 psi) |
Source: AirTAC Products Catalog 2026A (p.235, PDF01-P0237), GT200 ordering code and specifications.
How to choose
GTFR20006LNK differs from GTFR20006LK only in the gauge: both are low-pressure builds with the same check valve, 40 um element and 1/8 inch PT ports, but LNK leaves the body gaugeless. If you want the check valve plus a fitted indicator, order GTFR20006LK; without the check valve, GTFR20006LN is the plain gauge-free sibling.
Applications
Check-valved circuit builds
Branch layouts specified with a check valve in line, served by the K suffix while the regulator holds setpoints in the 0.15 - 0.4 MPa (20 - 58 psi) low band.
PLC-monitored pressure points
Machine lines where a controller reads pressure through its own transmitter, making the N-coded build without a gauge the correct variant to order.
Compact packaging panels
Shallow enclosures fed by 1/8 inch PT air lines, where the short PC bowl body and included mounting bracket keep the installation footprint small.
FAQ
Can you summarise the GTFR20006LNK specification?
1/8 inch (06) PT ports, low-pressure regulation 0.15 - 0.4 MPa (20 - 58 psi), 40 um filter element, short PC bowl with differential and manual drain, check valve (K), no gauge (N), mounting bracket included, fluid air.
How do GTFR20006LNK and GTFR20006LK compare?
Both are low-pressure GT200 units with a check valve, bracket, 40 um element and 1/8 inch PT ports; LK carries a fitted pressure gauge while LNK is the N-coded version without one. If panel indication is required, choose LK or plan your own external gauge with LNK.
