Airtac GTFR Filter Regulator GTFR20006LNW
Genuine AirTAC filter regulator, order code GTFR20006LNW from the GTFR200 range. The options this code selects are decoded below; series data follow the official AirTAC catalog.
- Port1/8" (06)
- Type · gaugeLow-pressure (L) · No gauge (N)
- ConfigurationWith bracket · 5 µm element (W) · PT thread
- Port1/8" (06), 1/4" (08)
- ThreadPT (standard)
- Filter element40 µm (standard), 5 µm (W)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GTFR Filter Regulator GTFR20006LNW
The GTFR20006LNW is the low-pressure, gaugeless build of the AirTAC GTFR200 filter regulator in the GT200 series, sized with 1/8" PT ports on the 06 body. Its L suffix sets the regulated range to 0.15 - 0.4 MPa (20 - 58 psi), so it suits circuits that run deliberately soft rather than full shop pressure. The W in the code specifies the 5 um element instead of the standard 40 um, giving finer particle removal for sensitive downstream tooling.
The short PC bowl keeps the footprint compact, which matters because GT200 is the short-bowl version of GA200 made for tight installations. The drain is differential plus manual, and because this code carries N, no pressure gauge is fitted - so mount your own gauge if you need to verify setpoints. A mounting bracket is included.
Airtac GTFR Filter Regulator GTFR20006LNW Technical Specifications
| Order code | GTFR20006LNW |
|---|---|
| Product | Filter Regulator |
| Port | 1/8" (06) |
| Type · gauge | Low-pressure (L) · No gauge (N) |
| Configuration | With bracket · 5 µm element (W) · PT thread |
| Port | 1/8" (06), 1/4" (08) |
|---|---|
| Thread | PT (standard) |
| Filter element | 40 µm (standard), 5 µm (W) |
| Bowl | Short PC bowl |
| Drain | Differential + manual |
| Fluid | Air |
| Low-pressure (L) version | 0.15 – 0.4 MPa (20 – 58 psi) |
Source: AirTAC Products Catalog 2026A (p.235, PDF01-P0237), GT200 ordering code and specifications.
How to choose
Choose GTFR20006LNW when your 1/8" line runs low pressure and you already have a gauge elsewhere in the circuit: the N option deletes the gauge and the bracket stays included. If you want the gauge factory-fitted, order GTFR20006LW instead; if the downstream circuit must hold pressure when supply is lost, step up to GTFR20006LNWK, which adds the check valve (K). For lines above 0.4 MPa use the standard S type rather than this L version.
Applications
Lab and test bench air
Setting gentle 0.15 - 0.4 MPa (20 - 58 psi) supply to instruments and bench rigs, with the 5 um element protecting delicate orifices and sensors.
Low-pressure sealing stations
Feeding bag-closing or gentle clamp circuits that deform at full line pressure, where the L range keeps actuator force predictable.
Compact panel mounting
Fitting regulation into narrow control cabinets, using the included bracket and short PC bowl, with an external gauge since this N code ships without one.
FAQ
What are the key specifications of the GTFR20006LNW?
Port: 1/8" (06), PT thread. Type: low-pressure L, regulated range 0.15 - 0.4 MPa (20 - 58 psi). Gauge: none (N code). Element: 5 um (W). Bowl: short PC, drain is differential plus manual. Mounting bracket: included. Fluid: air.
What do the N and W options change on this unit?
N removes the pressure gauge that a base GTFR200 normally carries, so read setpoints with your own gauge or regulator markings. W swaps the standard 40 um element for a 5 um element, trading a slightly higher pressure drop for cleaner air downstream.
