Airtac GTFR Filter Regulator GTFR20006LW
Genuine AirTAC filter regulator, order code GTFR20006LW from the GTFR200 range. The options this code selects are decoded below; series data follow the official AirTAC catalog.
- Port1/8" (06)
- Type · gaugeLow-pressure (L) · With gauge (MPa/psi)
- ConfigurationWith bracket · 5 µm element (W) · PT thread
- Port1/8" (06), 1/4" (08)
- ThreadPT (standard)
- Filter element40 µm (standard), 5 µm (W)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GTFR Filter Regulator GTFR20006LW
The GTFR20006LW is the gauge-fitted, low-pressure GTFR200 for 1/8" PT lines: with the L type the regulator works across 0.15 - 0.4 MPa (20 - 58 psi), and the on-board gauge shows the setpoint directly on the short PC bowl body, so fine low-pressure adjustments can be read while you turn the knob. The W element gives 5 um filtration instead of the standard 40 um.
As part of the GT200 series - the short-bowl version of GA200 - this unit fits where height is limited, and its differential plus manual drain clears condensate from the PC bowl. A mounting bracket is included. Because this code has no N or K letters, the gauge is fitted and no check valve is present.
Airtac GTFR Filter Regulator GTFR20006LW Technical Specifications
| Order code | GTFR20006LW |
|---|---|
| Product | Filter Regulator |
| Port | 1/8" (06) |
| Type · gauge | Low-pressure (L) · With gauge (MPa/psi) |
| Configuration | With bracket · 5 µm element (W) · PT thread |
| Port | 1/8" (06), 1/4" (08) |
|---|---|
| Thread | PT (standard) |
| Filter element | 40 µm (standard), 5 µm (W) |
| Bowl | Short PC bowl |
| Drain | Differential + manual |
| Fluid | Air |
| Low-pressure (L) version | 0.15 – 0.4 MPa (20 – 58 psi) |
Source: AirTAC Products Catalog 2026A (p.235, PDF01-P0237), GT200 ordering code and specifications.
How to choose
Pick GTFR20006LW over GTFR20006LNW when you want the pressure gauge supplied and fitted, saving you a separate gauge and port on a 1/8" circuit. If your circuit must retain pressure on air loss, the gaugeless GTFR20006LNWK adds the K check valve that this code does not have. For lines regulated above 0.4 MPa, the standard S type, not the L version, is the correct choice.
Applications
Delicate part handling
Vacuum-assist and soft-touch gripper circuits on 1/8" lines, tuned in the 0.15 - 0.4 MPa (20 - 58 psi) window and watched on the fitted gauge.
Gentle conveying and ejection
Low-blow-off and product-ejection jets where the 5 um element keeps nozzles clear and the L range prevents product damage.
Machine retrofits in tight frames
Adding visible low-pressure regulation inside existing guards, using the short PC bowl and included bracket where a full-depth GA200 unit will not fit.
FAQ
What are the key specifications of the GTFR20006LW?
Port: 1/8" (06), PT thread. Type: low-pressure L, regulated range 0.15 - 0.4 MPa (20 - 58 psi). Gauge: fitted, since this code has no N. Element: 5 um (W). Bowl: short PC with differential plus manual drain. Check valve: not fitted. Bracket: included.
How does this code differ from its 1/8" siblings?
GTFR20006LW differs from GTFR20006LNW only by the fitted gauge, and from GTFR20006LNWK by having no check valve. All three share the L low-pressure range, the W 5 um element, 1/8" PT ports, the short PC bowl and an included bracket.
