Airtac GTFR Filter Regulator GTFR20006LWK
Genuine AirTAC filter regulator, order code GTFR20006LWK from the GTFR200 range. The options this code selects are decoded below; series data follow the official AirTAC catalog.
- Port1/8" (06)
- Type · gaugeLow-pressure (L) · With gauge (MPa/psi)
- ConfigurationWith bracket · 5 µm element (W) · PT thread · Check valve (K)
- Port1/8" (06), 1/4" (08)
- ThreadPT (standard)
- Filter element40 µm (standard), 5 µm (W)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GTFR Filter Regulator GTFR20006LWK
The AirTAC GTFR20006LWK is the low-pressure, fine-filtration build of the GTFR200 filter regulator on a 1/8 inch (06) PT-threaded body. The L code sets the regulated output to 0.15 - 0.4 MPa (20 - 58 psi), a band the standard S type does not cover, and the W code fits the 5 um element in place of the standard 40 um element, so the unit steps air down gently and strips finer particles before the actuator. A pressure gauge is fitted, and the K position adds a check valve that a blank code leaves out.
Like every GTFR200, it uses a short PC bowl drained by differential plus manual action - the compact GT200 format that keeps the GA200 feature set in a smaller unit for tight spaces. The mounting bracket is included because this code carries no J.
Airtac GTFR Filter Regulator GTFR20006LWK Technical Specifications
| Order code | GTFR20006LWK |
|---|---|
| Product | Filter Regulator |
| Port | 1/8" (06) |
| Type · gauge | Low-pressure (L) · With gauge (MPa/psi) |
| Configuration | With bracket · 5 µm element (W) · PT thread · Check valve (K) |
| Port | 1/8" (06), 1/4" (08) |
|---|---|
| Thread | PT (standard) |
| Filter element | 40 µm (standard), 5 µm (W) |
| Bowl | Short PC bowl |
| Drain | Differential + manual |
| Fluid | Air |
| Low-pressure (L) version | 0.15 – 0.4 MPa (20 – 58 psi) |
Source: AirTAC Products Catalog 2026A (p.235, PDF01-P0237), GT200 ordering code and specifications.
How to choose
Choose GTFR20006LWK when the circuit runs below ordinary shop-air settings: the L type regulates 0.15 - 0.4 MPa (20 - 58 psi), while GTFR20006S is the standard-pressure sibling. This 06 code matches 1/8 inch lines; GTFR20008LWK moves the same configuration to 1/4 inch (08) ports. Adding N would delete the gauge, dropping W would return the 40 um element, and a T or G in the thread position would switch PT to NPT or G.
Applications
Low-pressure paint and glue feed
Dispensing and atomizing air circuits that work at gentle settings stay inside the 0.15 - 0.4 MPa (20 - 58 psi) L band, with the 5 um W element protecting nozzle orifices.
Downstream hold on supply dips
The K check valve on the 1/8 inch PT line suits points where downstream air should not simply escape back upstream the moment supply pressure falls.
Gauged low-pressure tuning
The fitted pressure gauge lets operators read and adjust settings inside the L range directly on the unit, useful for pilot and instrument branches.
FAQ
What are the key figures of the GTFR20006LWK?
Port 1/8 inch (code 06), PT thread; low-pressure L type regulating 0.15 - 0.4 MPa (20 - 58 psi); 5 um filter element (W); differential plus manual drain on a short PC bowl; pressure gauge fitted; mounting bracket included; check valve included (K); fluid air.
What do the W and K positions in the order code change?
W replaces the standard 40 um element with a 5 um element for cleaner air, and K adds a check valve - a blank K position means the unit ships without one.
