Airtac GTFR Filter Regulator GTFR20006SJWK
Genuine AirTAC filter regulator, order code GTFR20006SJWK from the GTFR200 range. The options this code selects are decoded below; series data follow the official AirTAC catalog.
- Port1/8" (06)
- Type · gaugeStandard (S) · With gauge (MPa/psi)
- ConfigurationNo bracket (J) · 5 µm element (W) · PT thread · Check valve (K)
- Port1/8" (06), 1/4" (08)
- ThreadPT (standard)
- Filter element40 µm (standard), 5 µm (W)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GTFR Filter Regulator GTFR20006SJWK
This GT200-series filter regulator combines filtering and pressure regulation in one short PC bowl body, the compact alternative to the deeper GA200 for cramped cabinets and manifolds. Condensate is handled by a differential drain that bleeds automatically, backed by a manual drain for dumping the bowl on demand.
The W in this order code selects the 5 um element instead of the catalog-standard 40 um, and K adds a check valve that protects downstream settings when upstream supply is interrupted. J deletes the mounting bracket, so confirm your mounting surface carries the unit directly. The standard S type ships with a pressure gauge fitted.
Airtac GTFR Filter Regulator GTFR20006SJWK Technical Specifications
| Order code | GTFR20006SJWK |
|---|---|
| Product | Filter Regulator |
| Port | 1/8" (06) |
| Type · gauge | Standard (S) · With gauge (MPa/psi) |
| Configuration | No bracket (J) · 5 µm element (W) · PT thread · Check valve (K) |
| Port | 1/8" (06), 1/4" (08) |
|---|---|
| Thread | PT (standard) |
| Filter element | 40 µm (standard), 5 µm (W) |
| Bowl | Short PC bowl |
| Drain | Differential + manual |
| Fluid | Air |
| Low-pressure (L) version | 0.15 – 0.4 MPa (20 – 58 psi) |
Source: AirTAC Products Catalog 2026A (p.235, PDF01-P0237), GT200 ordering code and specifications.
How to choose
Choose this code when your line is 1/8 in (06 port) and you need finer 5 um air with backflow protection. For 1/4 in piping step up to an 08 port code. If 40 um filtration is adequate and you want the bracket included, the sibling with check valve is GTFR20006SK; if you can accept the standard element but no bracket, drop only the K and keep W.
Applications
Instrument and sensor air
The 5 um element filters out finer particles than the standard 40 um, which suits delicate pneumatic sensors and measuring devices fed through a 1/8 in line.
Small pick-and-place cells
A short PC bowl and 1/8 in PT ports keep the unit compact beside small grippers and cylinders, while the check valve holds the regulated setting during supply dips.
Bench-top process rigs
The fitted MPa/psi gauge and differential plus manual drain give repeatable, clean regulated air for test benches without needing a bracket on the frame.
FAQ
What are the key figures of GTFR20006SJWK?
Port: 1/8 in PT (06 code). Standard pressure type with MPa/psi gauge. Filter element: 5 um (W). Drain: differential plus manual. Check valve included (K). No mounting bracket (J). Short PC bowl, fluid: air.
Why does this code have no mounting bracket?
The J in the order code deletes the bracket that a blank configuration includes. If the unit later needs to hang on a frame or panel, switch to the bracketed sibling in the same series and confirm details from the datasheet.
