Airtac HFKL Guided Parallel Type Pneumatic Gripper HFKL25F
Genuine AirTAC long-stroke parallel gripper, order code HFKL25F from the HFKL range. The options this code selects are decoded below; series data follow the official AirTAC catalog.
- BoreØ25 mm
- Jaw mountingBottom mounting
- Jaw widthStandard jaw
- ActionDouble acting
- GuideIntegrated crossed-roller linear guide
- Ø10closing 11 N · opening 17 N · stroke 8 mm · 64 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac HFKL Guided Parallel Type Pneumatic Gripper HFKL25F
The HFKL25F pairs the Dia 25 mm long-stroke HFKL platform with the F jaw code, bottom mounting: your fingers are secured underneath the jaws, which drops the grip point below the guide body, useful in tight vertical spaces or where the top of the jaw must stay clear. It is double acting, so air closes and opens the jaws, running on the integrated crossed-roller linear guide with 22 mm total stroke and +/-0.01 mm repeatability.
At 0.5 MPa with gripping distance L = 20 mm, one jaw closes with 69 N and opens with 102 N. The catalog lists the Dia 25 F-jaw version at 484 g against 489 g for the standard jaw, so the bottom-mounting jaw saves a few grams on the tool side. Ports are M5x0.8, pressure range is 0.15-0.7 MPa, no lubrication is required and the magnet in every unit supports CMSH/DMSH/EMSH or CMSG/DMSG/EMSG switches in the body grooves without brackets.
Airtac HFKL Guided Parallel Type Pneumatic Gripper HFKL25F Technical Specifications
| Order code | HFKL25F |
|---|---|
| Product | Long-Stroke Parallel Gripper |
| Bore | Ø25 mm |
| Jaw mounting | Bottom mounting |
| Jaw width | Standard jaw |
| Action | Double acting |
|---|---|
| Guide | Integrated crossed-roller linear guide |
| Ø10 | closing 11 N · opening 17 N · stroke 8 mm · 64 g |
| Ø16 | closing 34 N · opening 45 N · stroke 12 mm · 146 g |
| Ø20 | closing 45 N · opening 68 N · stroke 18 mm · 273 g (275 g with F jaw) |
| Ø25 | closing 69 N · opening 102 N · stroke 22 mm · 489 g (484 g with F jaw) |
| Fluid | Air (filtered by 40 µm element) |
| Operating pressure | 0.2-0.7 MPa on Ø10, 0.15-0.7 MPa on Ø16 and up |
| Temperature | -20 to +70 °C |
| Lubrication | Not required |
| Repeatability | ±0.01 mm |
| Max frequency | 120 c.p.m. |
| Port | M3×0.5 (Ø10), M5×0.8 (Ø16 and up) |
| Sensors | CMSH/DMSH/EMSH; CMSG/DMSG/EMSG on Ø16 and up |
Source: AirTAC Products Catalog 2026A (PDF01-P0644..P0645), HFKL series specifications and ordering code. Forces are per jaw at 0.5 MPa, gripping distance L = 20 mm.
How to choose
Order the HFKL25F when fingers must hang below the jaw, for example gripping parts under a low ceiling or over a fixture. If the fingers attach on top, use the plain HFKL25 standard jaw; for side bolts choose the HFKL25B, and for through-bolt fixing choose the HFKL25N. On bore size, the HFKL20 offers 45 N closing and 68 N opening force with 18 mm stroke if the Dia 25 closing force of 69 N exceeds what the part can tolerate, and a longer gripping distance than L = 20 mm lowers the usable force, so confirm the working point from the datasheet.
Applications
Carton and cartoner feeding
Bottom-mounted fingers reach under carton flaps or trays, and the 22 mm stroke opens wide enough to release flat packages without skimming the guides above.
Vision inspection handling
With fingers below the jaw, the top face and part view stay unobstructed for cameras, while a CMSG, DMSG or EMSG switch in the square groove confirms open and closed positions.
Electronics subassembly placement
The 484 g F-jaw version with +/-0.01 mm repeatability places connectors and covers into fixtures, with the 0.15-0.7 MPa pressure range letting you tune grip force for delicate housings.
FAQ
What are the key figures of the AirTAC HFKL25F?
Dia 25 mm bore, double acting, closing 69 N and opening 102 N per jaw at 0.5 MPa at gripping distance L = 20 mm, total stroke 22 mm, M5x0.8 ports, operating pressure 0.15-0.7 MPa, weight 484 g with the F jaw, repeatability +/-0.01 mm, temperature -20 to +70 C, maximum frequency 120 c.p.m.
Why choose bottom mounting, and what does it weigh?
The F code selects the bottom-mounting jaw, so fingers are fixed underneath the jaw and the grip point sits below the guide body, keeping the jaw top face free. The catalog lists 484 g for the Dia 25 F-jaw version versus 489 g for the standard jaw; forces, stroke and pressure range are unchanged across the jaw variants.
