Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-10
The AirTAC JSIJ63~80 Adjustable Cylinder JSIJ63X100-10 is a genuine double acting, double rod, adjustable stroke JIS-standard air cylinder with a Ø63mm bore and 100mm stroke, G3/8 air ports and adjustable end cushioning. Its no-tie-rod, hard-anodized profile barrel is more compact than an ISO 15552 cylinder of the same bore — a space-saver on tight machines.
- BoreØ63 mm
- Stroke100 mm
- Port sizeG3/8
- Acting typeDouble acting, double rod, adjustable stroke
- Rod threadM18×1.5
- CushionAdjustable, 29 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-10
The hard-anodized aluminum profile barrel makes it shorter and more compact than a same-bore ISO 15552 cylinder, while the G3/8 port supplies ample airflow for 30-800 mm/s speeds.
An external stop screw lets you shorten the extend stroke by up to 10 mm right at the machine, giving a usable range of 90-100 mm without swapping the cylinder. This adjuster sets the end position rather than locking the load, as the air cushion only decelerates the piston near the ends. Note this non-magnetized SKU cannot take a sensor.
Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-10 Technical Specifications
| Model | Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-10 |
|---|---|
| Series | JSI JIS-standard profile cylinder |
| Bore size | Ø63 mm |
| Stroke | 100 mm |
| Acting type | Double acting, double rod, adjustable stroke |
| Port size | G3/8 |
| Rod thread | M18×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 29 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC JSI (JIS standard) datasheet. Confirm against the product label before installation. Thread options: PT (blank) / G. Barrel: hard-anodized aluminum profile (no tie rods).
Theoretical Output Force (Ø63mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 1402 N | 1402 N |
| 0.7 MPa | 1962 N | 1962 N |
| Max (@1.0 MPa) | 286 kgf | |
JSIJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative).
Model Code: Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-10
| JSIJ | JIS-standard profile cylinder (adjustable-stroke type). |
|---|---|
| 63 | Bore size in mm (32 / 40 / 50 / 63 / 80 / 100 / 125). |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensors. |
JSI-family variants: JSI (double acting), JSID (double rod), JSIJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / TCM1 / TCM2. Thread PT (blank) / G.
Where the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-10 Is Used
Clamp Stroke Tuning
Dial in the exact 90-100 mm extend reach on a machining fixture to clamp varying part thicknesses without rebuilding the tooling.
Transfer Stopper
Adjust the stop position on a transfer line by up to 10 mm to accommodate different product lengths on the fly.
Is the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-10 the Right Cylinder?
The 10 mm adjuster is ideal for fine-tuning end positions on shared spares across stroke variants. Mounting options include FA, LB, TC, TCM1, and TCM2. If you need position feedback, select the -S variant for CMSE/DMSE sensors. For this 100 mm stroke, ensure adequate side-load guidance.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Set cushions to minimum, then release gradually.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-10 FAQ
The theoretical maximum force is 318 kgf at 1.0 MPa. It features a 20 mm rod, M18x1.5 rod thread, and G3/8 port.
The nominal 100 mm stroke is the maximum. An external stop screw lets you shorten the extend stroke by up to 10 mm on-site, giving a usable extend range of 90-100 mm. The retract end remains fixed. This mechanism only sets the end position and does not hold the load on air loss.
