Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-20
The AirTAC JSIJ63~80 Adjustable Cylinder JSIJ63X100-20 is a genuine double acting, double rod, adjustable stroke JIS-standard air cylinder with a Ø63mm bore and 100mm stroke, G3/8 air ports and adjustable end cushioning. Its no-tie-rod, hard-anodized profile barrel is more compact than an ISO 15552 cylinder of the same bore — a space-saver on tight machines.
- BoreØ63 mm
- Stroke100 mm
- Port sizeG3/8
- Acting typeDouble acting, double rod, adjustable stroke
- Rod threadM18×1.5
- CushionAdjustable, 29 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-20
The hard-anodized aluminum profile barrel keeps the total envelope shorter than a same-bore ISO 15552 unit, saving valuable machine space without losing power. A G3/8 port supplies air, while adjustable cushions at both ends absorb end-of-stroke impact.
The external adjuster lets you trim the extend stroke by up to 20 mm, yielding a usable range of 80 to 100 mm without changing the cylinder itself. Note this SKU lacks a magnet and cannot take a CMSE/DMSE sensor; add the -S variant for position detection.
Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-20 Technical Specifications
| Model | Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-20 |
|---|---|
| Series | JSI JIS-standard profile cylinder |
| Bore size | Ø63 mm |
| Stroke | 100 mm |
| Acting type | Double acting, double rod, adjustable stroke |
| Port size | G3/8 |
| Rod thread | M18×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 29 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC JSI (JIS standard) datasheet. Confirm against the product label before installation. Thread options: PT (blank) / G. Barrel: hard-anodized aluminum profile (no tie rods).
Theoretical Output Force (Ø63mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 1402 N | 1402 N |
| 0.7 MPa | 1962 N | 1962 N |
| Max (@1.0 MPa) | 286 kgf | |
JSIJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative).
Model Code: Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-20
| JSIJ | JIS-standard profile cylinder (adjustable-stroke type). |
|---|---|
| 63 | Bore size in mm (32 / 40 / 50 / 63 / 80 / 100 / 125). |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensors. |
JSI-family variants: JSI (double acting), JSID (double rod), JSIJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / TCM1 / TCM2. Thread PT (blank) / G.
Where the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-20 Is Used
Press Fit Tuning
Dial in the exact 80 to 100 mm extend position on-site to seat bearings without bottoming out the tooling.
Variable Stroke Divert
Adjust the extend stop to push varying package widths onto a secondary line without swapping cylinders.
Pallet Stop Adjustment
Fine-tune the retract stop distance on the fly to accommodate different pallet depths arriving at a station.
Is the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-20 the Right Cylinder?
The -20 mm adjustable window is perfect for fine-tuning end positions or sharing a spare across 80 to 100 mm stroke variants. Mounting options include FA, LB, TC, TCM1, and TCM2. For any stroke at or over 300 mm, use a guide rail to prevent rod side-loading. Remember this non-magnetic SKU cannot support sensors; choose the -S version if you need CMSE/DMSE switches.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Set cushions to minimum, then release gradually.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-20 FAQ
At 0.5 MPa it pushes 1559 N and pulls 1402 N. At 0.7 MPa it pushes 2182 N and pulls 1962 N. The theoretical maximum force is 318 kgf at 1.0 MPa. The air port is G3/8.
The nominal 100 mm stroke is the maximum. An external stop screw lets you shorten the extend stroke on-site by up to 20 mm, giving a usable extend range of 80 to 100 mm. The retract end is fixed. This mechanism only sets the end position and does not lock the load.
