Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-20S
The AirTAC JSIJ63~80 Adjustable Cylinder JSIJ63X100-20S is a genuine double acting, double rod, adjustable stroke JIS-standard air cylinder with a Ø63mm bore and 100mm stroke, G3/8 air ports and adjustable end cushioning. Its no-tie-rod, hard-anodized profile barrel is more compact than an ISO 15552 cylinder of the same bore — a space-saver on tight machines.
- BoreØ63 mm
- Stroke100 mm
- Port sizeG3/8
- Acting typeDouble acting, double rod, adjustable stroke
- Rod threadM18×1.5
- CushionAdjustable, 29 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-20S
The hard-anodized aluminum barrel leaves out external tie rods, making the body noticeably shorter and more compact than a same-bore ISO 15552 unit. A built-in piston magnet (-S) supports CMSE and DMSE reed or electronic switches that drop directly into the side grooves.
The external adjuster lets you shorten the extend stroke on-site by up to 20 mm, giving a usable range of 80 to 100 mm without swapping the cylinder. Pneumatic connections use a G3/8 port, and the adjustable air cushions at both ends decelerate the load smoothly.
Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-20S Technical Specifications
| Model | Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-20S |
|---|---|
| Series | JSI JIS-standard profile cylinder |
| Bore size | Ø63 mm |
| Stroke | 100 mm |
| Acting type | Double acting, double rod, adjustable stroke |
| Port size | G3/8 |
| Rod thread | M18×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 29 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC JSI (JIS standard) datasheet. Confirm against the product label before installation. Thread options: PT (blank) / G. Barrel: hard-anodized aluminum profile (no tie rods).
Theoretical Output Force (Ø63mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 1402 N | 1402 N |
| 0.7 MPa | 1962 N | 1962 N |
| Max (@1.0 MPa) | 286 kgf | |
JSIJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative).
Model Code: Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-20S
| JSIJ | JIS-standard profile cylinder (adjustable-stroke type). |
|---|---|
| 63 | Bore size in mm (32 / 40 / 50 / 63 / 80 / 100 / 125). |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensors. |
JSI-family variants: JSI (double acting), JSID (double rod), JSIJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / TCM1 / TCM2. Thread PT (blank) / G.
Where the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-20S Is Used
End-Position Trimming
Dial in the exact extend stop on a clamping fixture by shortening the stroke up to 20 mm on-site, avoiding mechanical shim adjustments.
Is the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-20S the Right Cylinder?
The adjustable stroke is ideal for fine-tuning the extend end position on-site or keeping one shared spare across multiple stroke variants. Mounting options include FA, LB, TC, TCM1, and TCM2 brackets. Because this SKU includes the -S magnet, you can fit CMSE/DMSE sensors directly. For any stroke length of 300 mm or longer, always use a guide rail to prevent side-load damage.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Set cushions to minimum, then release gradually.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-20S FAQ
The theoretical maximum force is 318 kgf at 1.0 MPa. The air port size is G3/8.
The nominal 100 mm extend stroke is the maximum. The external stop screw lets you shorten the extend stroke on-site by up to 20 mm, yielding a usable range of 80 to 100 mm. The retract end remains fixed, and the cushion only decelerates the load without holding it.
