Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-40
The AirTAC JSIJ63~80 Adjustable Cylinder JSIJ63X100-40 is a genuine double acting, double rod, adjustable stroke JIS-standard air cylinder with a Ø63mm bore and 100mm stroke, G3/8 air ports and adjustable end cushioning. Its no-tie-rod, hard-anodized profile barrel is more compact than an ISO 15552 cylinder of the same bore — a space-saver on tight machines.
- BoreØ63 mm
- Stroke100 mm
- Port sizeG3/8
- Acting typeDouble acting, double rod, adjustable stroke
- Rod threadM18×1.5
- CushionAdjustable, 29 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-40
The extruded hard-anodized aluminium barrel omits tie rods entirely, making the overall body shorter and more compact than a same-bore ISO 15552 unit.
The JSIJ63X100-40 uses a 40 mm external adjuster window to shorten the extend stroke on-site, letting you fine-tune the 60 to 100 mm end position without swapping the cylinder. Air connects via a G3/8 port, and adjustable 29 mm cushions decelerate the load at both ends. Because this SKU lacks a magnet, it cannot take a CMSE or DMSE sensor; add the -S variant for position detection.
Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-40 Technical Specifications
| Model | Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-40 |
|---|---|
| Series | JSI JIS-standard profile cylinder |
| Bore size | Ø63 mm |
| Stroke | 100 mm |
| Acting type | Double acting, double rod, adjustable stroke |
| Port size | G3/8 |
| Rod thread | M18×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 29 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC JSI (JIS standard) datasheet. Confirm against the product label before installation. Thread options: PT (blank) / G. Barrel: hard-anodized aluminum profile (no tie rods).
Theoretical Output Force (Ø63mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 1402 N | 1402 N |
| 0.7 MPa | 1962 N | 1962 N |
| Max (@1.0 MPa) | 286 kgf | |
JSIJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative).
Model Code: Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-40
| JSIJ | JIS-standard profile cylinder (adjustable-stroke type). |
|---|---|
| 63 | Bore size in mm (32 / 40 / 50 / 63 / 80 / 100 / 125). |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensors. |
JSI-family variants: JSI (double acting), JSID (double rod), JSIJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / TCM1 / TCM2. Thread PT (blank) / G.
Where the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-40 Is Used
End-Stop Trimming
Dial in the exact extend contact point within the 40 mm window on a clamping fixture without machining new hard stops.
Transfer Diverter
Shorten the extend stroke on-site to deflect packages of varying widths precisely onto secondary routing lanes.
Shared Spare Stock
Keep one cylinder as a universal replacement for 60 to 100 mm extend applications, adjusting the stop as needed during installation.
Is the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-40 the Right Cylinder?
The 40 mm adjustable window is ideal for sharing one spare across multiple stroke variants or dialing in final end positions on-site. Mounting options include FA, LB, TC, TCM1, and TCM2 brackets. For any stroke length at or above 300 mm, always guide the load to prevent side-load damage to the rod seals.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Set cushions to minimum, then release gradually.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-40 FAQ
This 63 mm bore cylinder pushes 1559 N and pulls 1402 N at 0.5 MPa, pushing 2182 N and pulling 1962 N at 0.7 MPa, with a theoretical max of 318 kgf at 1.0 MPa. The air port is G3/8.
The nominal 100 mm extend stroke is the maximum. An external stop screw lets you shorten the extend stroke on-site by up to 40 mm, giving a usable range of 60 to 100 mm. The retract end remains fixed. Note that a plain cylinder does not hold load on air loss; use an external rod lock or pilot-operated check valve for holding.
