Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-40S
The AirTAC JSIJ63~80 Adjustable Cylinder JSIJ63X100-40S is a genuine double acting, double rod, adjustable stroke JIS-standard air cylinder with a Ø63mm bore and 100mm stroke, G3/8 air ports and adjustable end cushioning. Its no-tie-rod, hard-anodized profile barrel is more compact than an ISO 15552 cylinder of the same bore — a space-saver on tight machines.
- BoreØ63 mm
- Stroke100 mm
- Port sizeG3/8
- Acting typeDouble acting, double rod, adjustable stroke
- Rod threadM18×1.5
- CushionAdjustable, 29 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-40S
Its hard-anodized extruded aluminum barrel makes it shorter and more compact than a same-bore ISO 15552 unit. The integrated G3/8 port keeps air flow generous for the 30-800 mm/s speed range.
The -40 code means an external stop screw lets you shorten the extend stroke on-site by up to 40 mm, giving a usable 60-100 mm window while the retract end stays fixed. Because the -S suffix denotes a built-in piston magnet, you can drop CMSE or DMSE reed and electronic switches straight into the side grooves.
Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-40S Technical Specifications
| Model | Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-40S |
|---|---|
| Series | JSI JIS-standard profile cylinder |
| Bore size | Ø63 mm |
| Stroke | 100 mm |
| Acting type | Double acting, double rod, adjustable stroke |
| Port size | G3/8 |
| Rod thread | M18×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 29 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC JSI (JIS standard) datasheet. Confirm against the product label before installation. Thread options: PT (blank) / G. Barrel: hard-anodized aluminum profile (no tie rods).
Theoretical Output Force (Ø63mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 1402 N | 1402 N |
| 0.7 MPa | 1962 N | 1962 N |
| Max (@1.0 MPa) | 286 kgf | |
JSIJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative).
Model Code: Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-40S
| JSIJ | JIS-standard profile cylinder (adjustable-stroke type). |
|---|---|
| 63 | Bore size in mm (32 / 40 / 50 / 63 / 80 / 100 / 125). |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensors. |
JSI-family variants: JSI (double acting), JSID (double rod), JSIJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / TCM1 / TCM2. Thread PT (blank) / G.
Where the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-40S Is Used
End-Position Trimming
Dial in the exact extend stop on a clamping fixture by shortening the 100 mm stroke up to 40 mm on-site without changing the mount.
Variable Transfer Push
Adjust the push-off distance for different product sizes on a packaging line using the external stop screw window.
Is the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-40S the Right Cylinder?
The adjustable stroke is ideal for sharing one spare across multiple stroke variants or fine-tuning the end position without swapping the cylinder. Mounting options include FA, LB, TC, TCM1, and TCM2. The -S magnet supports CMSE/DMSE sensors. For any stroke over 300 mm, always use a guide rail to prevent side-load damage.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Set cushions to minimum, then release gradually.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-40S FAQ
At 0.5 MPa it pushes 1559 N and pulls 1402 N. At 0.7 MPa it pushes 2182 N and pulls 1962 N. The theoretical maximum force is 318 kgf at 1.0 MPa. The air port is G3/8.
The 40 mm window means an external adjuster shortens the extend stroke on-site from the 100 mm maximum down to 60 mm. The retract end is fixed. This stop only sets the end position; it does not hold the load on air loss.
