Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-50
The AirTAC JSIJ63~80 Adjustable Cylinder JSIJ63X100-50 is a genuine double acting, double rod, adjustable stroke JIS-standard air cylinder with a Ø63mm bore and 100mm stroke, G3/8 air ports and adjustable end cushioning. Its no-tie-rod, hard-anodized profile barrel is more compact than an ISO 15552 cylinder of the same bore — a space-saver on tight machines.
- BoreØ63 mm
- Stroke100 mm
- Port sizeG3/8
- Acting typeDouble acting, double rod, adjustable stroke
- Rod threadM18×1.5
- CushionAdjustable, 29 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-50
Its extruded hard-anodized aluminium barrel makes it shorter and more compact than a same-bore ISO 15552 unit. The G3/8 ported body carries a 20 mm rod and adjustable air cushions at both ends.
The -50 code means an external stop screw lets you shorten the extend stroke on-site by up to 50 mm. You get a usable extend range of 50 to 100 mm without changing the cylinder, while the retract end stays fixed. This plain SKU lacks a magnet and cannot take a sensor; add the -S variant for CMSE/DMSE switches.
Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-50 Technical Specifications
| Model | Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-50 |
|---|---|
| Series | JSI JIS-standard profile cylinder |
| Bore size | Ø63 mm |
| Stroke | 100 mm |
| Acting type | Double acting, double rod, adjustable stroke |
| Port size | G3/8 |
| Rod thread | M18×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 29 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC JSI (JIS standard) datasheet. Confirm against the product label before installation. Thread options: PT (blank) / G. Barrel: hard-anodized aluminum profile (no tie rods).
Theoretical Output Force (Ø63mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 1402 N | 1402 N |
| 0.7 MPa | 1962 N | 1962 N |
| Max (@1.0 MPa) | 286 kgf | |
JSIJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative).
Model Code: Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-50
| JSIJ | JIS-standard profile cylinder (adjustable-stroke type). |
|---|---|
| 63 | Bore size in mm (32 / 40 / 50 / 63 / 80 / 100 / 125). |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensors. |
JSI-family variants: JSI (double acting), JSID (double rod), JSIJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / TCM1 / TCM2. Thread PT (blank) / G.
Where the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-50 Is Used
Press Fit Tuning
Fine-tune the 50 to 100 mm extend stroke on-site to set exact pressing depth for bearing insertion without swapping cylinders.
Variable Diverter
Adjust the external stop screw to change the push distance for routing different package sizes on a packaging line.
Shared Spare Stock
Keep one 100 mm nominal cylinder as a universal spare, shortening the extend stroke up to 50 mm to fit multiple machines.
Is the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-50 the Right Cylinder?
The JSIJ series supports Basic, FA, LB, TC, TCM1 and TCM2 mounts. The adjustable stroke is ideal for sharing one spare across stroke variants or fine-tuning end positions on-site. Because this is a no-magnet SKU, you cannot fit position sensors. For any stroke over 300 mm, guide the load to prevent side-load wear on the 20 mm rod seal.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Set cushions to minimum, then release gradually.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-50 FAQ
At 0.5 MPa it pushes 1559 N and pulls 1402 N. At 0.7 MPa it pushes 2182 N and pulls 1962 N. The theoretical maximum force is 318 kgf at 1.0 MPa. It uses a G3/8 port and a 20 mm rod.
The external stop screw lets you shorten the extend stroke by up to 50 mm on-site, giving a usable extend range of 50 to 100 mm. The nominal 100 mm stroke is the maximum. The retract end is fixed. This stop sets the end position and is not a load lock.
