Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-50S
The AirTAC JSIJ63~80 Adjustable Cylinder JSIJ63X100-50S is a genuine double acting, double rod, adjustable stroke JIS-standard air cylinder with a Ø63mm bore and 100mm stroke, G3/8 air ports and adjustable end cushioning. Its no-tie-rod, hard-anodized profile barrel is more compact than an ISO 15552 cylinder of the same bore — a space-saver on tight machines.
- BoreØ63 mm
- Stroke100 mm
- Port sizeG3/8
- Acting typeDouble acting, double rod, adjustable stroke
- Rod threadM18×1.5
- CushionAdjustable, 29 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-50S
The hard-anodized aluminum profile barrel keeps the overall body shorter and more compact than a same-bore ISO 15552 cylinder.
The -50 code means an external adjuster can shorten the extend stroke by up to 50 mm on site, giving a usable range of 50 to 100 mm without changing the cylinder itself. Because this is an -S SKU, a built-in piston magnet lets you drop CMSE or DMSE reed and electronic switches directly into the side grooves. Pneumatic connections use a G3/8 port, and adjustable air cushions at both ends absorb end-of-stroke impact.
Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-50S Technical Specifications
| Model | Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-50S |
|---|---|
| Series | JSI JIS-standard profile cylinder |
| Bore size | Ø63 mm |
| Stroke | 100 mm |
| Acting type | Double acting, double rod, adjustable stroke |
| Port size | G3/8 |
| Rod thread | M18×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 29 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC JSI (JIS standard) datasheet. Confirm against the product label before installation. Thread options: PT (blank) / G. Barrel: hard-anodized aluminum profile (no tie rods).
Theoretical Output Force (Ø63mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 1402 N | 1402 N |
| 0.7 MPa | 1962 N | 1962 N |
| Max (@1.0 MPa) | 286 kgf | |
JSIJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative).
Model Code: Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-50S
| JSIJ | JIS-standard profile cylinder (adjustable-stroke type). |
|---|---|
| 63 | Bore size in mm (32 / 40 / 50 / 63 / 80 / 100 / 125). |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensors. |
JSI-family variants: JSI (double acting), JSID (double rod), JSIJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / TCM1 / TCM2. Thread PT (blank) / G.
Where the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-50S Is Used
Press Fit Tuning
Dial in the exact 50 to 100 mm extend position on-site to seat delicate bearings without bottoming out the stroke.
Variable Length Diverter
Adjust the extend stop to deflect different package sizes on a single line, saving the cost of multiple cylinders.
Is the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-50S the Right Cylinder?
This model sits perfectly in the middle for medium-duty tasks. The adjustable stroke is ideal when you need to fine-tune an end position across multiple machine variants or share one spare across similar stroke lengths. Mounting options include FA, LB, TC, TCM1, and TCM2. The integrated magnet supports CMSE/DMSE sensors. For any stroke at or over 300 mm, always use external guide rails to prevent side-load damage.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Set cushions to minimum, then release gradually.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-50S FAQ
The theoretical maximum force is 318 kgf at 1.0 MPa. The air port is G3/8.
The nominal 100 mm stroke is the maximum. An external stop screw lets you shorten the extend stroke by up to 50 mm on-site, yielding a usable range of 50 to 100 mm. The retract end is fixed. This stop sets the end position but does not lock the load.
