Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-75
The AirTAC JSIJ63~80 Adjustable Cylinder JSIJ63X100-75 is a genuine double acting, double rod, adjustable stroke JIS-standard air cylinder with a Ø63mm bore and 100mm stroke, G3/8 air ports and adjustable end cushioning. Its no-tie-rod, hard-anodized profile barrel is more compact than an ISO 15552 cylinder of the same bore — a space-saver on tight machines.
- BoreØ63 mm
- Stroke100 mm
- Port sizeG3/8
- Acting typeDouble acting, double rod, adjustable stroke
- Rod threadM18×1.5
- CushionAdjustable, 29 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-75
The extruded hard-anodized aluminium barrel omits external rods, leaving a smooth body that is physically shorter and more compact than a same-bore ISO 15552 unit. A G3/8 port feeds the 20 mm piston rod, while adjustable 29 mm air cushions bookend each stroke.
The external stop screw lets you trim the extend stroke on-site by up to 75 mm, dropping the usable forward travel from the 100 mm maximum down to 25 mm without swapping the actuator. Note that this plain SKU lacks a magnet and cannot take a CMSE or DMSE sensor.
Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-75 Technical Specifications
| Model | Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-75 |
|---|---|
| Series | JSI JIS-standard profile cylinder |
| Bore size | Ø63 mm |
| Stroke | 100 mm |
| Acting type | Double acting, double rod, adjustable stroke |
| Port size | G3/8 |
| Rod thread | M18×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 29 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC JSI (JIS standard) datasheet. Confirm against the product label before installation. Thread options: PT (blank) / G. Barrel: hard-anodized aluminum profile (no tie rods).
Theoretical Output Force (Ø63mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 1402 N | 1402 N |
| 0.7 MPa | 1962 N | 1962 N |
| Max (@1.0 MPa) | 286 kgf | |
JSIJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative).
Model Code: Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-75
| JSIJ | JIS-standard profile cylinder (adjustable-stroke type). |
|---|---|
| 63 | Bore size in mm (32 / 40 / 50 / 63 / 80 / 100 / 125). |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensors. |
JSI-family variants: JSI (double acting), JSID (double rod), JSIJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / TCM1 / TCM2. Thread PT (blank) / G.
Where the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-75 Is Used
Press Fit Tuning
Dial in the exact 25 to 100 mm extend position for pressing bearings without machining custom spacers.
Variable Diverter Gate
Adjust the pusher reach on-site to deflect different package sizes on a single sorting line.
Adjustable Sealing Jaw
Shift the extend stop to accommodate various carton depths while maintaining fixed retract spacing.
Is the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-75 the Right Cylinder?
The 75 mm adjust window is ideal when you need to fine-tune the extend end position across multiple fixtures or share one spare across stroke variants. Mounting options include Basic, FA, LB, TC, TCM1, and TCM2 brackets. Because this non-magnetic SKU lacks a piston magnet, it cannot accept position sensors. For any stroke at or over 300 mm, always guide the load to prevent side-load damage to the rod seals.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Set cushions to minimum, then release gradually.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X100-75 FAQ
The theoretical maximum force is 318 kgf at 1.0 MPa. The G3/8 port and 20 mm rod support these outputs.
The nominal 100 mm extend stroke is the maximum. An external stop screw lets you shorten the forward travel on-site by up to 75 mm, leaving a usable extend range of 25 to 100 mm. The retract end is fixed. This stop only sets position; it is not a load lock.
