Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-10
The AirTAC JSIJ63~80 Adjustable Cylinder JSIJ63X1000-10 is a genuine double acting, double rod, adjustable stroke JIS-standard air cylinder with a Ø63mm bore and 1000mm stroke, G3/8 air ports and adjustable end cushioning. Its no-tie-rod, hard-anodized profile barrel is more compact than an ISO 15552 cylinder of the same bore — a space-saver on tight machines.
- BoreØ63 mm
- Stroke1000 mm
- Port sizeG3/8
- Acting typeDouble acting, double rod, adjustable stroke
- Rod threadM18×1.5
- CushionAdjustable, 29 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-10
The extruded hard-anodized aluminium body omits tie rods entirely, leaving a smooth exterior that is notably shorter and more compact than an equivalent ISO 15552 unit.
An external stop screw lets you trim the extend stroke by up to 10 mm on site, giving a usable range of 990-1000 mm without swapping the actuator. The retract end remains fixed, and the G3/8 port feeds adjustable 29 mm air cushions at both ends. Because there is no -S suffix, this SKU cannot take a magnetic switch.
Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-10 Technical Specifications
| Model | Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-10 |
|---|---|
| Series | JSI JIS-standard profile cylinder |
| Bore size | Ø63 mm |
| Stroke | 1000 mm |
| Acting type | Double acting, double rod, adjustable stroke |
| Port size | G3/8 |
| Rod thread | M18×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 29 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC JSI (JIS standard) datasheet. Confirm against the product label before installation. Thread options: PT (blank) / G. Barrel: hard-anodized aluminum profile (no tie rods).
Theoretical Output Force (Ø63mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 1402 N | 1402 N |
| 0.7 MPa | 1962 N | 1962 N |
| Max (@1.0 MPa) | 286 kgf | |
JSIJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative).
Model Code: Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-10
| JSIJ | JIS-standard profile cylinder (adjustable-stroke type). |
|---|---|
| 63 | Bore size in mm (32 / 40 / 50 / 63 / 80 / 100 / 125). |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensors. |
JSI-family variants: JSI (double acting), JSID (double rod), JSIJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / TCM1 / TCM2. Thread PT (blank) / G.
Where the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-10 Is Used
Transfer Line Indexing
Trims the final 10 mm of a 1000 mm extend to synchronise pallet stops precisely on a long conveyor belt.
Long-Stroke Press Down
Lowers a forming head 990 mm, adjusting the final 10 mm on-site to set the exact material compression height.
Is the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-10 the Right Cylinder?
The 10 mm extend-trim window is ideal for sharing a single spare across slightly different stroke variants or fine-tuning an end position after a mechanical change. Mounting options include FA, LB, TC, TCM1, and TCM2 brackets. As this is a no-S SKU, it cannot accept CMSE/DMSE sensors. Because the 1000 mm stroke is long, always support the load with an external guide to prevent rod bending and side-load damage.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Set cushions to minimum, then release gradually.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-10 FAQ
The 63 mm bore uses a G3/8 port, a 20 mm rod with an M18x1.5 thread, and 29 mm adjustable air cushions. Speed ranges from 30-800 mm/s.
The nominal 1000 mm stroke is the maximum. The external adjuster lets you shorten the extend stroke by up to 10 mm on site, yielding a usable range of 990-1000 mm. The retract end is fixed. Note that this stop only sets the end position; it does not lock the load. For load holding on air loss, use an external rod lock or pilot-operated check valve.
