Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-100
The AirTAC JSIJ63~80 Adjustable Cylinder JSIJ63X1000-100 is a genuine double acting, double rod, adjustable stroke JIS-standard air cylinder with a Ø63mm bore and 1000mm stroke, G3/8 air ports and adjustable end cushioning. Its no-tie-rod, hard-anodized profile barrel is more compact than an ISO 15552 cylinder of the same bore — a space-saver on tight machines.
- BoreØ63 mm
- Stroke1000 mm
- Port sizeG3/8
- Acting typeDouble acting, double rod, adjustable stroke
- Rod threadM18×1.5
- CushionAdjustable, 29 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-100
The G3/8 ported body uses an extruded hard-anodized aluminium profile barrel, making it shorter and more compact than a same-bore ISO 15552 cylinder.
The external stop screw provides a 100 mm adjustment window, letting you fine-tune the usable extend stroke down from the 1000 mm maximum to 900 mm on-site without changing the cylinder itself. Because this SKU lacks the -S magnet option, it cannot take a CMSE or DMSE sensor. Note that the retract end is fixed, and the adjustable cushion only decelerates the load; it does not hold it on air loss.
Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-100 Technical Specifications
| Model | Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-100 |
|---|---|
| Series | JSI JIS-standard profile cylinder |
| Bore size | Ø63 mm |
| Stroke | 1000 mm |
| Acting type | Double acting, double rod, adjustable stroke |
| Port size | G3/8 |
| Rod thread | M18×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 29 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC JSI (JIS standard) datasheet. Confirm against the product label before installation. Thread options: PT (blank) / G. Barrel: hard-anodized aluminum profile (no tie rods).
Theoretical Output Force (Ø63mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 1402 N | 1402 N |
| 0.7 MPa | 1962 N | 1962 N |
| Max (@1.0 MPa) | 286 kgf | |
JSIJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative).
Model Code: Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-100
| JSIJ | JIS-standard profile cylinder (adjustable-stroke type). |
|---|---|
| 63 | Bore size in mm (32 / 40 / 50 / 63 / 80 / 100 / 125). |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensors. |
JSI-family variants: JSI (double acting), JSID (double rod), JSIJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / TCM1 / TCM2. Thread PT (blank) / G.
Where the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-100 Is Used
Long-Transfer Push-Off
Uses the full 1000 mm stroke to push parts off a conveyor, with the 100 mm window allowing precise end-position tuning against a varying backstop.
Material Lowering Stage
Lowers heavy fixtures along a 1000 mm path, relying on the 29 mm adjustable air cushions to decelerate the load smoothly at the fixed retract end.
Is the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-100 the Right Cylinder?
The 100 mm on-site extend-shortening window is ideal for tuning end positions during commissioning or sharing a single spare across multiple stroke variants. You can mount it via FA, LB, TC, TCM1, or TCM2 brackets. Because the stroke is 1000 mm, always use an external guide to prevent rod bending and side loads. This non-magnet version cannot support position sensing.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Set cushions to minimum, then release gradually.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-100 FAQ
This 63 mm bore cylinder features a G3/8 air port and an M18x1.5 rod thread.
The nominal 1000 mm stroke is the maximum. An external stop screw lets you shorten the extend stroke by up to 100 mm on-site, giving a usable extend range of 900 to 1000 mm. The retract end remains fixed, and this stop is for positioning only, not for holding a load.
