Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-10S
The AirTAC JSIJ63~80 Adjustable Cylinder JSIJ63X1000-10S is a genuine double acting, double rod, adjustable stroke JIS-standard air cylinder with a Ø63mm bore and 1000mm stroke, G3/8 air ports and adjustable end cushioning. Its no-tie-rod, hard-anodized profile barrel is more compact than an ISO 15552 cylinder of the same bore — a space-saver on tight machines.
- BoreØ63 mm
- Stroke1000 mm
- Port sizeG3/8
- Acting typeDouble acting, double rod, adjustable stroke
- Rod threadM18×1.5
- CushionAdjustable, 29 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-10S
Its extruded hard-anodized aluminium barrel omits tie rods, making the overall body shorter and more space-efficient than a same-bore ISO 15552 unit. The G3/8 port feeds a double-acting double rod that drives 30-800 mm/s.
An external stop screw provides a 10 mm on-site extend-shortening window, letting you fine-tune the end position from 990 to 1000 mm without swapping the actuator. The -S suffix means a built-in magnet for CMSE/DMSE sensors in the side grooves. Note that the retract end is fixed, and the cushions only decelerate; use an external rod lock for holding.
Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-10S Technical Specifications
| Model | Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-10S |
|---|---|
| Series | JSI JIS-standard profile cylinder |
| Bore size | Ø63 mm |
| Stroke | 1000 mm |
| Acting type | Double acting, double rod, adjustable stroke |
| Port size | G3/8 |
| Rod thread | M18×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 29 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC JSI (JIS standard) datasheet. Confirm against the product label before installation. Thread options: PT (blank) / G. Barrel: hard-anodized aluminum profile (no tie rods).
Theoretical Output Force (Ø63mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 1402 N | 1402 N |
| 0.7 MPa | 1962 N | 1962 N |
| Max (@1.0 MPa) | 286 kgf | |
JSIJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative).
Model Code: Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-10S
| JSIJ | JIS-standard profile cylinder (adjustable-stroke type). |
|---|---|
| 63 | Bore size in mm (32 / 40 / 50 / 63 / 80 / 100 / 125). |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensors. |
JSI-family variants: JSI (double acting), JSID (double rod), JSIJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / TCM1 / TCM2. Thread PT (blank) / G.
Where the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-10S Is Used
Long-Transfer Pushing
Moves pallets along a 1000 mm conveyor section, using the 10 mm adjuster to dial in the exact push-off distance without reprogramming the machine.
Vertical Material Lift
Raises 79 kg racks in a storage buffer, relying on the compact JIS profile to fit tight vertical columns while the cushion decelerates the load.
Indexing Station Stop
Acts as a hard stop for parts arriving on a line, fine-tuning the 990-1000 mm extended position on-site to match varying product widths.
Is the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-10S the Right Cylinder?
If you need less force, the 50 mm bore offers 982 N; for heavier drives, the 80 mm bore provides 2513 N. The 10 mm adjustable window is ideal for sharing a spare across stroke variants or finalizing end positions on-site. Mounting options include FA, LB, TC, TCM1, and TCM2. The -S magnet supports CMSE/DMSE switches. Because the stroke is 1000 mm, external guides are critical to prevent rod bending and manage side loads.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Set cushions to minimum, then release gradually.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-10S FAQ
At 0.5 MPa it pushes 1559 N and pulls 1402 N. At 0.7 MPa it pushes 2182 N and pulls 1962 N. The theoretical maximum force is 318 kgf at 1.0 MPa. This 63 mm bore unit uses a G3/8 air port and features a 29 mm adjustable air cushion at both ends.
The nominal 1000 mm stroke is the maximum. An external stop screw lets you shorten the extend stroke by up to 10 mm on-site, giving a usable range of 990-1000 mm for precise end-position tuning. The retract end remains fixed. This mechanism sets the stop position and does not lock the load; you need a pilot-operated check valve for holding.
