The AirTAC JSIJ63~80 Adjustable Cylinder JSIJ63X1000-30 is a genuine double acting, double rod, adjustable stroke JIS-standard air cylinder with a Ø63mm bore and 1000mm stroke, G3/8 air ports and adjustable end cushioning. Its no-tie-rod, hard-anodized profile barrel is more compact than an ISO 15552 cylinder of the same bore — a space-saver on tight machines.
Its extruded hard-anodized aluminium barrel omits tie rods entirely, making the overall body shorter and more compact than a same-bore ISO 15552 unit.
The -30 code means an external adjuster can shorten the 1000 mm extend stroke on-site by up to 30 mm, yielding a usable 970-1000 mm range without swapping the cylinder. This lets you fine-tune the end position mechanically. Note this plain SKU lacks a magnet and cannot take a sensor; adding the -S variant enables CMSE/DMSE switches.
| Model | Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-30 |
|---|---|
| Series | JSI JIS-standard profile cylinder |
| Bore size | Ø63 mm |
| Stroke | 1000 mm |
| Acting type | Double acting, double rod, adjustable stroke |
| Port size | G3/8 |
| Rod thread | M18×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 29 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC JSI (JIS standard) datasheet. Confirm against the product label before installation. Thread options: PT (blank) / G. Barrel: hard-anodized aluminum profile (no tie rods).
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 1402 N | 1402 N |
| 0.7 MPa | 1962 N | 1962 N |
| Max (@1.0 MPa) | 286 kgf | |
JSIJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative).
| JSIJ | JIS-standard profile cylinder (adjustable-stroke type). |
|---|---|
| 63 | Bore size in mm (32 / 40 / 50 / 63 / 80 / 100 / 125). |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensors. |
JSI-family variants: JSI (double acting), JSID (double rod), JSIJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / TCM1 / TCM2. Thread PT (blank) / G.
Moves heavy pallets along a 1000 mm conveyor section, using the 30 mm adjuster to dial in the exact push-off distance on-site.
Actuates a long diverting gate where the 970-1000 mm extend window allows precise alignment without re-mounting the actuator.
The JSIJ series mounting options include FA, LB, TC, TCM1, and TCM2 brackets. The adjustable stroke is ideal when you need on-site end-position tuning or want a shared spare across stroke variants. Because the 1000 mm stroke is long, always support the load with an external guide to prevent rod bending and side-load damage. Remember this no-magnet SKU cannot accept a sensor.
Quick checklist
The theoretical max force is 318 kgf at 1.0 MPa. It uses a G3/8 port, has a 20 mm rod, and features 29 mm adjustable air cushions at both ends.
The 1000 mm nominal stroke is the maximum. An external stop screw lets you shorten the extend stroke on-site by up to 30 mm, giving a usable range of 970-1000 mm. The retract end remains fixed. This mechanism sets the end position and is not a load lock; for load holding on air loss, use an external rod lock or pilot-operated check valve.
