Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-30S
The AirTAC JSIJ63~80 Adjustable Cylinder JSIJ63X1000-30S is a genuine double acting, double rod, adjustable stroke JIS-standard air cylinder with a Ø63mm bore and 1000mm stroke, G3/8 air ports and adjustable end cushioning. Its no-tie-rod, hard-anodized profile barrel is more compact than an ISO 15552 cylinder of the same bore — a space-saver on tight machines.
- BoreØ63 mm
- Stroke1000 mm
- Port sizeG3/8
- Acting typeDouble acting, double rod, adjustable stroke
- Rod threadM18×1.5
- CushionAdjustable, 29 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-30S
The external adjuster allows you to shorten the extend stroke on-site by up to 30 mm, yielding a usable travel of 970-1000 mm without swapping the actuator. It features a hard-anodized aluminum barrel and is noticeably shorter than a same-bore ISO 15552 unit. The -S suffix adds a piston magnet for CMSE/DMSE sensors.
Air connects via a G3/8 port, and adjustable cushions protect the ends. Note that the stop screw sets position only; for load holding on air loss, install an external rod lock or pilot-operated check valve.
Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-30S Technical Specifications
| Model | Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-30S |
|---|---|
| Series | JSI JIS-standard profile cylinder |
| Bore size | Ø63 mm |
| Stroke | 1000 mm |
| Acting type | Double acting, double rod, adjustable stroke |
| Port size | G3/8 |
| Rod thread | M18×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 29 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC JSI (JIS standard) datasheet. Confirm against the product label before installation. Thread options: PT (blank) / G. Barrel: hard-anodized aluminum profile (no tie rods).
Theoretical Output Force (Ø63mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 1402 N | 1402 N |
| 0.7 MPa | 1962 N | 1962 N |
| Max (@1.0 MPa) | 286 kgf | |
JSIJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative).
Model Code: Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-30S
| JSIJ | JIS-standard profile cylinder (adjustable-stroke type). |
|---|---|
| 63 | Bore size in mm (32 / 40 / 50 / 63 / 80 / 100 / 125). |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensors. |
JSI-family variants: JSI (double acting), JSID (double rod), JSIJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / TCM1 / TCM2. Thread PT (blank) / G.
Where the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-30S Is Used
Long-Transfer Push
Moves pallets along a conveyor, using the 30 mm adjuster to dial in the exact 970 mm push distance for different fixture stops.
High-Bay Extraction
Extracts totes from deep shelving racks, relying on the magnetic -S sensor to confirm full 1000 mm retraction.
Long-Reach Clamping
Extends to clamp large workpieces, fine-tuning the final 970-1000 mm end position without reprogramming the machine.
Is the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-30S the Right Cylinder?
The -30 mm adjustable window is ideal for fine-tuning a long 1000 mm extend stroke on-site or sharing a spare across similar travel lengths. Mounting options include FA, LB, TC, TCM1, and TCM2. The -S magnet supports CMSE/DMSE switches. Because the stroke is 1000 mm, always use external guides to prevent rod bending and manage side loads.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Set cushions to minimum, then release gradually.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-30S FAQ
The G3/8 port supplies air to the 20 mm rod.
The nominal 1000 mm stroke is the maximum. An external stop screw lets you shorten the extend stroke by up to 30 mm on-site, giving a usable range of 970-1000 mm. The retract end remains fixed.
