Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-40
The AirTAC JSIJ63~80 Adjustable Cylinder JSIJ63X1000-40 is a genuine double acting, double rod, adjustable stroke JIS-standard air cylinder with a Ø63mm bore and 1000mm stroke, G3/8 air ports and adjustable end cushioning. Its no-tie-rod, hard-anodized profile barrel is more compact than an ISO 15552 cylinder of the same bore — a space-saver on tight machines.
- BoreØ63 mm
- Stroke1000 mm
- Port sizeG3/8
- Acting typeDouble acting, double rod, adjustable stroke
- Rod threadM18×1.5
- CushionAdjustable, 29 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-40
The hard-anodized aluminum barrel omits external rods, making the overall body shorter and more compact than a same-bore ISO 15552 unit.
The -40 code defines an external adjuster that shortens the extend stroke on-site by up to 40 mm, giving a usable range of 960 to 1000 mm while the retract end remains fixed. You can fine-tune the end position without physically remounting the cylinder. Pneumatic connections use a G3/8 port, and because this specific SKU lacks a magnet, it cannot accept CMSE or DMSE sensors.
Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-40 Technical Specifications
| Model | Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-40 |
|---|---|
| Series | JSI JIS-standard profile cylinder |
| Bore size | Ø63 mm |
| Stroke | 1000 mm |
| Acting type | Double acting, double rod, adjustable stroke |
| Port size | G3/8 |
| Rod thread | M18×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 29 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC JSI (JIS standard) datasheet. Confirm against the product label before installation. Thread options: PT (blank) / G. Barrel: hard-anodized aluminum profile (no tie rods).
Theoretical Output Force (Ø63mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 1402 N | 1402 N |
| 0.7 MPa | 1962 N | 1962 N |
| Max (@1.0 MPa) | 286 kgf | |
JSIJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative).
Model Code: Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-40
| JSIJ | JIS-standard profile cylinder (adjustable-stroke type). |
|---|---|
| 63 | Bore size in mm (32 / 40 / 50 / 63 / 80 / 100 / 125). |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensors. |
JSI-family variants: JSI (double acting), JSID (double rod), JSIJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / TCM1 / TCM2. Thread PT (blank) / G.
Where the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-40 Is Used
Long-Reach Transfer
Pushes parts across a wide conveyor belt, using the 40 mm adjuster to dial in the exact hand-off distance without moving the cylinder mounts.
High-Bay Extraction
Extracts totes from deep shelving racks, where the 1000 mm reach is necessary and the end-position can be fine-tuned on-site to clear the shelf lip.
Multi-Station Indexing
Drives a long carriage across machining stations, using the adjustable stop to synchronize the final resting position with the tooling center.
Is the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-40 the Right Cylinder?
The 40 mm adjustable window is highly useful for synchronizing end positions across multiple stations or absorbing minor mechanical drift without swapping parts. Mounting choices include Basic, FA, LB, TC, TCM1, and TCM2. Because the 1000 mm stroke is long, always support the rod against side loads with an external guide to prevent bending. Note this non-magnet version cannot host position sensors.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Set cushions to minimum, then release gradually.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-40 FAQ
The theoretical maximum force is 318 kgf at 1.0 MPa. It features a 20 mm rod, a G3/8 port, an M18x1.5 rod thread, and 29 mm adjustable air cushions at both ends.
The nominal 1000 mm stroke is the maximum length. The external -40 adjuster allows you to shorten the extend stroke on-site by up to 40 mm, providing a usable extend range of 960 to 1000 mm. The retract end remains fixed, and this stop only sets the end position—it does not lock or hold the load.
