Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-50S
The AirTAC JSIJ63~80 Adjustable Cylinder JSIJ63X1000-50S is a genuine double acting, double rod, adjustable stroke JIS-standard air cylinder with a Ø63mm bore and 1000mm stroke, G3/8 air ports and adjustable end cushioning. Its no-tie-rod, hard-anodized profile barrel is more compact than an ISO 15552 cylinder of the same bore — a space-saver on tight machines.
- BoreØ63 mm
- Stroke1000 mm
- Port sizeG3/8
- Acting typeDouble acting, double rod, adjustable stroke
- Rod threadM18×1.5
- CushionAdjustable, 29 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-50S
Delivering 1559 N of extend push at 0.5 MPa, this 63 mm bore JIS profile cylinder is built for long-reach tasks. The extruded hard-anodized aluminum body omits tie rods entirely, making it shorter and more compact than a same-bore ISO 15552 unit. A G3/8 port supplies air, while a 29 mm adjustable cushion decelerates the 30-800 mm/s piston at each end.
The -50 code defines an external stop screw that lets you shorten the extend stroke on-site by up to 50 mm, giving a usable range of 950-1000 mm without swapping the actuator. The -S suffix adds a piston magnet for CMSE/DMSE switches in the side grooves.
Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-50S Technical Specifications
| Model | Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-50S |
|---|---|
| Series | JSI JIS-standard profile cylinder |
| Bore size | Ø63 mm |
| Stroke | 1000 mm |
| Acting type | Double acting, double rod, adjustable stroke |
| Port size | G3/8 |
| Rod thread | M18×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 29 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC JSI (JIS standard) datasheet. Confirm against the product label before installation. Thread options: PT (blank) / G. Barrel: hard-anodized aluminum profile (no tie rods).
Theoretical Output Force (Ø63mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 1402 N | 1402 N |
| 0.7 MPa | 1962 N | 1962 N |
| Max (@1.0 MPa) | 286 kgf | |
JSIJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative).
Model Code: Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-50S
| JSIJ | JIS-standard profile cylinder (adjustable-stroke type). |
|---|---|
| 63 | Bore size in mm (32 / 40 / 50 / 63 / 80 / 100 / 125). |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensors. |
JSI-family variants: JSI (double acting), JSID (double rod), JSIJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / TCM1 / TCM2. Thread PT (blank) / G.
Where the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-50S Is Used
Transfer Line Indexing
Pushes pallets down a long 1000 mm transfer lane, using the 50 mm extend adjuster to dial in the exact stop position for different fixture widths.
High-Bay Pusher Arm
Actuates a long push-off arm on a packaging line, relying on the compact JIS profile to save axial space while moving loads safely.
Material Forming Stop
Sets the raw material length in a forming press, making on-site adjustments to the 950-1000 mm extend window as part tolerances shift.
Is the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-50S the Right Cylinder?
This 63 mm actuator hits a solid middle ground. The 50 mm adjuster window is highly useful when you need to fine-tune a long end-position on-site or standardize a shared spare across stroke variants. JSIJ mounting choices include FA, LB, TC, TCM1, and TCM2. Because the stroke is 1000 mm, always support the load with external guides to prevent rod bending and side-load damage.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Set cushions to minimum, then release gradually.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-50S FAQ
The theoretical maximum force is 318 kgf at 1.0 MPa.
The nominal 1000 mm stroke is the maximum. An external stop screw lets you shorten the extend stroke on-site by up to 50 mm, yielding a usable range of 950-1000 mm. The retract end remains fixed. This stop sets the end position and is not a load lock.
