Airtac M5Y Rocker Type Mechanical Valve M5Y21006G
2. M5B/M5R/M5L series utilize externally supplied actuation force for switching, enabling position detection or travel switch applications.
3. M5C/M5D/M5Y/M5PF/M5PM/M5PP/M5PL/M5HS series feature manual operation with diversified actuator configurations, optimized for diverse operating conditions.
4. Spool-type structure ensures consistent control force independent of working pressure (zero backpressure effect). Internal sealing design guarantees superior leak-tightness and responsive directional switching.
5. Oil-free lubrication system eliminates maintenance requirements.
6. Multiple mounting orientations enhance installation flexibility and operational convenience.
7. Metal actuators in M5C/M5D/M5Y/M5R/M5L series ensure extended service life with reinforced reliability and stability.
Category: Mechanical Valves | Brand: Airtac | Series: M5Y
AirTAC M5Y21006G Lever-Operated Mechanical Valve Specifications
- Model: M5Y21006G
- Type: 3-position closed-center lever valve (mechanical actuation)
- Port size: PT1/4 (G1/4 thread)
- Operating pressure: 0.1–0.8 MPa
- Operating force: ≤3N lever actuation force
- Flow capacity: 850 L/min (ANR)
- Weight: 215g ±5g
- Dimensions: 56mm(L) × 38mm(W) × 72mm(H)
- Body material: Aluminum alloy (anodized finish)
- Seal material: HNBR rubber (oil & heat resistant)
- Temperature range: -20℃ to 80℃ (non-freezing)
- Response time: ≤50ms (full stroke operation)
- Mounting orientation: Vertical ±15° recommended
- Port alignment: 3-port configuration (P: pressure, A/B: actuators, R: exhaust)
Manual override valve with tactile lever feedback, designed for emergency operation or maintenance modes in automated systems. Features zero-power operation capability and wear-resistant pivot mechanism. The dual-seal structure prevents cross-port leakage even under vibration conditions.
- Production line emergency stop systems
- Semiconductor wafer handling robots
- Food processing equipment manual override
- Automated warehouse conveyor jams clearance
- Test bench pneumatic circuit configuration
Installation note:
Lubricate lever pivot quarterly with ISO VG32 hydraulic oil.
Ensure exhaust port faces downward when vertical installation
isn't possible to prevent debris accumulation. Maximum lateral
tubing load: 5N.
| Property | Property Value |
|---|---|
| sku | M5Y21006G |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
