Airtac MBLD Dual Axis Type Mini Cylinder MBLD20X160
The AirTAC MBLD Dual Axis Type Mini Cylinder MBLD20X160 is a genuine double-acting double-rod aluminum-barrel mini cylinder with a Ø20mm bore and 160mm stroke. A rod exits both end covers, so extend and retract force are EQUAL — about 132 N each way at 0.5 MPa. Fixed rubber bumper.
- BoreØ20 mm
- Stroke160 mm
- Port sizeG1/8
- Acting typeDouble acting, double rod
- Rod threadM8×1.25
- CushionFixed rubber bumper
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MBLD Dual Axis Type Mini Cylinder MBLD20X160
The AirTAC MBLD20X160 is a compact double-acting double-rod aluminum mini cylinder. A single piston drives an Ø8 mm hard-chrome rod out of both end covers, yielding identical extend and retract forces of 132 N at 0.5 MPa. This 160 mm stroke is well-suited for mid-travel positioning tasks where symmetrical thrust prevents directional drift.
Because a rod occupies both sides, the annulus area is identical in each direction, ensuring equal speed and force. The rear protruding rod can host a cam or position flag, while the twin-rod geometry inherently resists twist better than a single rod. This base SKU lacks a built-in magnet, so it cannot accept CMSG, DMSG, or EMSG position sensors. End impact is absorbed by a fixed rubber bumper, and the body uses a riveted rolling-packed aluminum barrel with a grease-retaining piston seal.
Airtac MBLD Dual Axis Type Mini Cylinder MBLD20X160 Technical Specifications
| Model | Airtac MBLD Dual Axis Type Mini Cylinder MBLD20X160 |
|---|---|
| Series | MBL aluminum-barrel mini round cylinder (double rod) |
| Bore size | Ø20 mm |
| Stroke | 160 mm |
| Acting type | Double acting, double rod |
| Port size | G1/8 |
| Rod thread | M8×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed rubber bumper |
| Max standard stroke | Up to 300 mm |
Double-rod overall length = A + 2 × stroke — leave clearance for the rear rod. MBLD/MBLCD mounting is Basic / FA / LB only (no SDB, no back-cover code). Thread options: PT / G / NPT.
Output Force (Ø20mm, equal both ways)
| Pressure | Extend & retract force |
|---|---|
| 0.5 MPa | 132 N |
| 0.7 MPa | 185 N |
| Max (@1.0 MPa) | 27 kgf |
A rod on both piston faces makes the annulus area equal, so extend and retract force (and speed) are the same. Actual usable force is lower due to friction.
Model Code: Airtac MBLD Dual Axis Type Mini Cylinder MBLD20X160
| MBLD | MBLD aluminum-barrel double-rod mini cylinder. |
|---|---|
| 20 | Bore size in mm. |
| ×160 | Stroke length in mm. |
| S | Optional built-in magnet for a CMSG/DMSG/EMSG sensor switch. |
| FA / LB | Mounting: FA flange or LB foot (no SDB on double-rod). |
Related: MBLCD (double rod, adjustable cushion), MBLC (single rod + cushion), MBL (single rod).
Where the Airtac MBLD Dual Axis Type Mini Cylinder MBLD20X160 Is Used
PCB Edge Guide Transfer
Moves bare circuit boards between inspection stations using 132 N of equal thrust, utilizing the rear rod end to mount a mechanical position flag for timing.
Connector Pick-and-Place
Handles delicate electronic connectors over a 160 mm travel where symmetrical extend and retract speeds prevent sudden acceleration shifts in compact pickers.
Film Web Tracking
Adjusts a lightweight guide roller on packaging film lines, relying on the twin-rod anti-rotation property to keep the web aligned without skewing.
Is the Airtac MBLD Dual Axis Type Mini Cylinder MBLD20X160 the Right Cylinder?
When sizing this 20 mm bore, stepping down is not an option as it is the smallest available. Stepping up to the 25 mm bore raises the equal both-way force to 206 N at 0.5 MPa. This MBLD20X160 variant uses standard PT port threads and basic mounting; alternative mounts are limited to FA flange or LB foot brackets, as SDB pivot or back-cover options do not exist for the double-rod series.
For a direct replacement, match the 20 mm bore, 160 mm stroke, G1/8 port, PT thread, and basic mounting without a magnet. Since the overall length equals A plus 2 x stroke, you must leave rear-rod clearance. Although the twin rods improve rotational stability, the 8 mm rods over a 160 mm stroke still require an external guide to prevent bending under side loads. Note that the fixed rubber bumper softens end impact but does not lock the rod; without live air, the cylinder drifts.
Quick checklist
- ✓ Equal force both ways at your pressure
- ✓ Rear-rod clearance (length = A + 2 × stroke)
- ✓ Mounting: Basic / FA / LB only
- ✓ Magnet (S) for sensors?
- ✓ Side load — add a guide on long strokes
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Leave clearance for the rear rod (length = A + 2 × stroke).
- check Avoid side load; add an external guide on long strokes.
- check Mounting: Basic / FA flange / LB foot (no SDB, no back-cover code).
- check Installation by qualified personnel per AirTAC docs.
Airtac MBLD Dual Axis Type Mini Cylinder MBLD20X160 FAQ
The MBLD20X160 provides equal force in both directions because the rod exits both ends. It delivers 132 N at 0.5 MPa and 185 N at 0.7 MPa on both extend and retract, with a maximum theoretical output of 27 kgf at 1.0 MPa.
Unlike a single-rod cylinder where push force exceeds pull force, the MBLD20X160 has a rod on both sides, creating equal annulus areas for identical push and pull forces. The rear rod can drive a secondary mechanism or flag, but this specific SKU lacks a magnet, so it cannot support CMSG, DMSG, or EMSG electronic or reed sensors.
