Airtac MICJ Adjustable Mini Cylinder MICJ16X100-50S
The AirTAC MICJ Adjustable Mini Cylinder MICJ16X100-50S is a genuine double acting, double rod, adjustable stroke + cushion round-body mini air cylinder with a Ø16mm bore and 100mm stroke, M5×0.8 air ports and a stainless-steel barrel and rod for mildly corrosive environments. Its ISO 6432 mounting interface fits standard ISO 6432 mini-cylinder mounting interfaces.
- BoreØ16 mm
- Stroke100 mm
- Port sizeM5×0.8
- Acting typeDouble acting, double rod, adjustable stroke + cushion
- Rod threadM6×1.0
- CushionVariable air cushion, both ends
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MICJ Adjustable Mini Cylinder MICJ16X100-50S
Dial in your forward stop on the fly with the AirTAC MICJ16X100-50S, a stainless-steel round-body mini cylinder that cuts the extend stroke by up to 50 mm via an external screw. A needle-set adjustable air cushion at both ends soaks up high-speed shock, letting you set the position and control the impact simultaneously.
The stainless barrel and rod resist mild corrosion and washdown environments. Because this SKU includes the -S magnet, it is fully ready for CMSG, DMSG, or EMSG switches.
Airtac MICJ Adjustable Mini Cylinder MICJ16X100-50S Technical Specifications
| Model | Airtac MICJ Adjustable Mini Cylinder MICJ16X100-50S |
|---|---|
| Series | MICJ ISO 6432 mini cylinder |
| Bore size | Ø16 mm |
| Stroke | 100 mm |
| Acting type | Double acting, double rod, adjustable stroke + cushion |
| Port size | M5×0.8 |
| Rod thread | M6×1.0 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Variable air cushion, both ends |
| Max standard stroke | Up to 500 mm |
Specifications follow the official AirTAC MI/MIC (ISO 6432) datasheet. Barrel & rod: stainless steel (round-body, riveted construction). Thread options: PT (blank) / G.
Theoretical Output Force (Ø16mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 86 N |
| 0.7 MPa | 121 N |
| Max (@1.0 MPa) | 18 kgf |
MIJ / MICJ are double-rod: the rear rod that carries the stroke adjuster exits the rear cover, so both piston faces lose rod area. The rod-side (annular) area is used for both directions (conservative).
Model Code: Airtac MICJ Adjustable Mini Cylinder MICJ16X100-50S
| MICJ | ISO 6432 round-body mini cylinder (adjustable-stroke, variable cushion). |
|---|---|
| 16 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -50 | Adjustable stroke window (mm the extend stroke can be shortened on site). |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
MI-family variants: MI / MIC (double acting ±cushion), MSI / MTI (single acting push / pull), MID / MICD (double rod ±cushion), MIJ / MICJ (double rod, adjustable stroke ±cushion). Back covers CA / U / R / CM. Mounting LB / FA / SDB / TC.
Where the Airtac MICJ Adjustable Mini Cylinder MICJ16X100-50S Is Used
Carton Flap Folder
Folds light cardboard flaps at speed; the 50 mm adjuster dials in the exact fold depth without re-engineering the cell.
Lab Sample Stopper
Presses sample vials into trays with a 5.1 kg vertical lift margin, relying on the stainless build for wipe-down compatibility.
Is the Airtac MICJ Adjustable Mini Cylinder MICJ16X100-50S the Right Cylinder?
When sizing this bore, step down to a non-cushioned MIJ bumper type for lighter duties, or step up to a Ø20 MICJ if you need more push (157 N at 0.5 MPa). The MICJ16X100-50S shines in fast set-position moves where you need to tune the extend end without swapping hardware. It uses an LB foot, FA flange, or TC trunnion mount; the SDB pivot block is not offered on this adjustable variant.
Keep in mind the stop screw sets the end position but is not a mid-stroke lock. The cylinder will drift on air loss, and the air cushion only decelerates near the stroke end. Use an external rod lock or pilot check valve if the load must be held.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G)
- ✓ Magnet (-S) for sensors?
- ✓ Back cover (CA/U/R/CM) & mount (LB/FA/SDB/TC)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check Use correct back cover (CA/U/R/CM) & mount (LB/FA/SDB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac MICJ Adjustable Mini Cylinder MICJ16X100-50S FAQ
The theoretical maximum force is 20.5 kgf at 1.0 MPa.
An external screw shortens the extend stroke by up to 50 mm on-site, while the retract remains full. Needle valves adjust the air cushion at both ends to decelerate the piston before impact. This -S model includes a magnet for CMSG/DMSG/EMSG sensors.
