Airtac MICJ Adjustable Mini Cylinder MICJ16X100-75
The AirTAC MICJ Adjustable Mini Cylinder MICJ16X100-75 is a genuine double acting, double rod, adjustable stroke + cushion round-body mini air cylinder with a Ø16mm bore and 100mm stroke, M5×0.8 air ports and a stainless-steel barrel and rod for mildly corrosive environments. Its ISO 6432 mounting interface fits standard ISO 6432 mini-cylinder mounting interfaces.
- BoreØ16 mm
- Stroke100 mm
- Port sizeM5×0.8
- Acting typeDouble acting, double rod, adjustable stroke + cushion
- Rod threadM6×1.0
- CushionVariable air cushion, both ends
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MICJ Adjustable Mini Cylinder MICJ16X100-75
Dial in a precise forward stop on-site with the AirTAC MICJ16X100-75, a 16mm bore round-body stainless mini cylinder. An external screw trims the extend stroke by up to 75mm, giving a usable forward range of 25-100mm, while a needle-set air cushion at both ends absorbs high-speed shock. The stainless steel barrel and rod resist mild corrosion and washdown environments.
Built to the ISO 6432 mini-cylinder mounting interface, this double-acting actuator pushes with 100.5N and pulls with 86.4N at 0.5MPa via an M5×0.8 port. Note this SKU lacks a magnet, so it cannot host CMSG/DMSG/EMSG sensors.
Airtac MICJ Adjustable Mini Cylinder MICJ16X100-75 Technical Specifications
| Model | Airtac MICJ Adjustable Mini Cylinder MICJ16X100-75 |
|---|---|
| Series | MICJ ISO 6432 mini cylinder |
| Bore size | Ø16 mm |
| Stroke | 100 mm |
| Acting type | Double acting, double rod, adjustable stroke + cushion |
| Port size | M5×0.8 |
| Rod thread | M6×1.0 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Variable air cushion, both ends |
| Max standard stroke | Up to 500 mm |
Specifications follow the official AirTAC MI/MIC (ISO 6432) datasheet. Barrel & rod: stainless steel (round-body, riveted construction). Thread options: PT (blank) / G.
Theoretical Output Force (Ø16mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 86 N |
| 0.7 MPa | 121 N |
| Max (@1.0 MPa) | 18 kgf |
MIJ / MICJ are double-rod: the rear rod that carries the stroke adjuster exits the rear cover, so both piston faces lose rod area. The rod-side (annular) area is used for both directions (conservative).
Model Code: Airtac MICJ Adjustable Mini Cylinder MICJ16X100-75
| MICJ | ISO 6432 round-body mini cylinder (adjustable-stroke, variable cushion). |
|---|---|
| 16 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -75 | Adjustable stroke window (mm the extend stroke can be shortened on site). |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
MI-family variants: MI / MIC (double acting ±cushion), MSI / MTI (single acting push / pull), MID / MICD (double rod ±cushion), MIJ / MICJ (double rod, adjustable stroke ±cushion). Back covers CA / U / R / CM. Mounting LB / FA / SDB / TC.
Where the Airtac MICJ Adjustable Mini Cylinder MICJ16X100-75 Is Used
Carton Flap Folding
Dial in the exact forward position to fold light packaging flaps on the fly, relying on the stainless build for washdown resistance.
Lab Dispense Positioning
Set a specific extend length between 25-100mm for sample handling, using the M5×0.8 port actuator to move roughly 5kg safely.
Is the Airtac MICJ Adjustable Mini Cylinder MICJ16X100-75 the Right Cylinder?
For lighter duty, the MIJ bumper-only series is the next step down, as the cushioned MICJ line starts at this 16mm bore. If your application requires more force, stepping up to the 20mm bore raises the 0.5MPa push force to 157N. The 75mm extend trim is ideal for fast set-position moves where you need to tune the forward endpoint without swapping hardware.
Remember that the stop screw sets the end position but does not act as a mid-stroke lock; the piston will drift on air loss, so use an external rod lock or pilot check valve for held loads. Mount via LB foot, FA flange or TC trunnion (SDB pivot-block is not available on this adjustable variant). Add the -S suffix if you need magnetic sensing.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G)
- ✓ Magnet (-S) for sensors?
- ✓ Back cover (CA/U/R/CM) & mount (LB/FA/SDB/TC)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check Use correct back cover (CA/U/R/CM) & mount (LB/FA/SDB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac MICJ Adjustable Mini Cylinder MICJ16X100-75 FAQ
Its theoretical maximum force is 20.5kgf at 1.0MPa.
An external screw shortens the extend stroke by up to 75mm (retract stays full), while needle valves tune the air cushions at both ends to decelerate high-speed moves. The cushions only slow the piston near stroke end and do not lock; the piston drifts on air loss. This SKU has no magnet, so it cannot take sensors.
