Airtac MICJ Adjustable Mini Cylinder MICJ16X110-20S
The AirTAC MICJ Adjustable Mini Cylinder MICJ16X110-20S is a genuine double acting, double rod, adjustable stroke + cushion round-body mini air cylinder with a Ø16mm bore and 110mm stroke, M5×0.8 air ports and a stainless-steel barrel and rod for mildly corrosive environments. Its ISO 6432 mounting interface fits standard ISO 6432 mini-cylinder mounting interfaces.
- BoreØ16 mm
- Stroke110 mm
- Port sizeM5×0.8
- Acting typeDouble acting, double rod, adjustable stroke + cushion
- Rod threadM6×1.0
- CushionVariable air cushion, both ends
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MICJ Adjustable Mini Cylinder MICJ16X110-20S
Trim the forward stop by up to 20 mm on site without swapping hardware: this MICJ16X110-20S double-acting mini cylinder uses an external screw to shorten the extend end position from a 110 mm nominal stroke down to 90 mm, while the retract stroke remains full. A needle-set adjustable air cushion at both ends soaks up high-speed shock, letting you dial in the exact impact deceleration right at the stroke limits.
Built as a stainless-steel round-body riveted unit (never a tie-rod or profile design), the 16 mm bore pushes 100.5 N at 0.5 MPa. The -S suffix means a piston magnet is present for CMSG, DMSG or EMSG sensors. It uses an ISO 6432 mounting interface, accepts an M5×0.8 port, and the stainless barrel and rod resist mild washdown corrosion.
Airtac MICJ Adjustable Mini Cylinder MICJ16X110-20S Technical Specifications
| Model | Airtac MICJ Adjustable Mini Cylinder MICJ16X110-20S |
|---|---|
| Series | MICJ ISO 6432 mini cylinder |
| Bore size | Ø16 mm |
| Stroke | 110 mm |
| Acting type | Double acting, double rod, adjustable stroke + cushion |
| Port size | M5×0.8 |
| Rod thread | M6×1.0 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Variable air cushion, both ends |
| Max standard stroke | Up to 500 mm |
Specifications follow the official AirTAC MI/MIC (ISO 6432) datasheet. Barrel & rod: stainless steel (round-body, riveted construction). Thread options: PT (blank) / G.
Theoretical Output Force (Ø16mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 86 N |
| 0.7 MPa | 121 N |
| Max (@1.0 MPa) | 18 kgf |
MIJ / MICJ are double-rod: the rear rod that carries the stroke adjuster exits the rear cover, so both piston faces lose rod area. The rod-side (annular) area is used for both directions (conservative).
Model Code: Airtac MICJ Adjustable Mini Cylinder MICJ16X110-20S
| MICJ | ISO 6432 round-body mini cylinder (adjustable-stroke, variable cushion). |
|---|---|
| 16 | Bore size in mm. |
| ×110 | Stroke length in mm. |
| -20 | Adjustable stroke window (mm the extend stroke can be shortened on site). |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
MI-family variants: MI / MIC (double acting ±cushion), MSI / MTI (single acting push / pull), MID / MICD (double rod ±cushion), MIJ / MICJ (double rod, adjustable stroke ±cushion). Back covers CA / U / R / CM. Mounting LB / FA / SDB / TC.
Where the Airtac MICJ Adjustable Mini Cylinder MICJ16X110-20S Is Used
Light-Part Ejection
Pushes small molded parts off a conveyor at speed. The 20 mm extend trim dials out the exact ejection distance, while the dual air cushions absorb the high-frequency impact of rapid cycling.
Lab Sample Routing
The stainless build handles mild washdown, and the -S magnet tracks position via DMSG sensors.
Flap Deflection
Tamps light carton flaps at 0.5 MPa. The adjustable forward stop lets you tweak the flap contact point on the fly without loosening the ISO 6432 bracket bolts.
Is the Airtac MICJ Adjustable Mini Cylinder MICJ16X110-20S the Right Cylinder?
This 16 mm variant shines in fast set-position moves where the 20 mm extend trim prevents hard mechanical crashes.
Mount using LB foot, FA flange or TC trunnion brackets (the SDB pivot-block is not offered on this adjustable-stroke build). The stop screw sets the end position but is not a mid-stroke lock; the air cushion only decelerates near the end. Because a plain cylinder drifts on air loss, add an external rod lock or pilot check valve to hold a suspended load.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G)
- ✓ Magnet (-S) for sensors?
- ✓ Back cover (CA/U/R/CM) & mount (LB/FA/SDB/TC)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check Use correct back cover (CA/U/R/CM) & mount (LB/FA/SDB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac MICJ Adjustable Mini Cylinder MICJ16X110-20S FAQ
This 16 mm bore cylinder pushes 100.5 N and pulls 86.4 N at 0.5 MPa. At 0.7 MPa it pushes 140.7 N and pulls 120.9 N. The theoretical max force is 20.5 kgf at 1.0 MPa. It uses an M5×0.8 air port.
An external screw shortens the extend end position by up to 20 mm (usable extend 90-110 mm); the retract stroke stays full. A needle valve adjusts the air cushion at both ends to decelerate high-speed moves. The -S suffix means a piston magnet is built in for CMSG, DMSG or EMSG sensors.
