Airtac MICJ Adjustable Mini Cylinder MICJ16X125-10
The AirTAC MICJ Adjustable Mini Cylinder MICJ16X125-10 is a genuine double acting, double rod, adjustable stroke + cushion round-body mini air cylinder with a Ø16mm bore and 125mm stroke, M5×0.8 air ports and a stainless-steel barrel and rod for mildly corrosive environments. Its ISO 6432 mounting interface fits standard ISO 6432 mini-cylinder mounting interfaces.
- BoreØ16 mm
- Stroke125 mm
- Port sizeM5×0.8
- Acting typeDouble acting, double rod, adjustable stroke + cushion
- Rod threadM6×1.0
- CushionVariable air cushion, both ends
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MICJ Adjustable Mini Cylinder MICJ16X125-10
Trim the forward stop by up to 10 mm on site without swapping hardware using this stainless-steel, round-body mini cylinder. The external screw shortens the extend end position to a usable 115-125 mm, while the adjustable air cushion at both ends soaks up high-speed shock. It drops into standard ISO 6432 mini-cylinder mounting brackets and clevises.
This SKU lacks a magnet, so it cannot host CMSG, DMSG or EMSG sensors; choose the -S variant if you need position feedback.
Airtac MICJ Adjustable Mini Cylinder MICJ16X125-10 Technical Specifications
| Model | Airtac MICJ Adjustable Mini Cylinder MICJ16X125-10 |
|---|---|
| Series | MICJ ISO 6432 mini cylinder |
| Bore size | Ø16 mm |
| Stroke | 125 mm |
| Acting type | Double acting, double rod, adjustable stroke + cushion |
| Port size | M5×0.8 |
| Rod thread | M6×1.0 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Variable air cushion, both ends |
| Max standard stroke | Up to 500 mm |
Specifications follow the official AirTAC MI/MIC (ISO 6432) datasheet. Barrel & rod: stainless steel (round-body, riveted construction). Thread options: PT (blank) / G.
Theoretical Output Force (Ø16mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 86 N |
| 0.7 MPa | 121 N |
| Max (@1.0 MPa) | 18 kgf |
MIJ / MICJ are double-rod: the rear rod that carries the stroke adjuster exits the rear cover, so both piston faces lose rod area. The rod-side (annular) area is used for both directions (conservative).
Model Code: Airtac MICJ Adjustable Mini Cylinder MICJ16X125-10
| MICJ | ISO 6432 round-body mini cylinder (adjustable-stroke, variable cushion). |
|---|---|
| 16 | Bore size in mm. |
| ×125 | Stroke length in mm. |
| -10 | Adjustable stroke window (mm the extend stroke can be shortened on site). |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
MI-family variants: MI / MIC (double acting ±cushion), MSI / MTI (single acting push / pull), MID / MICD (double rod ±cushion), MIJ / MICJ (double rod, adjustable stroke ±cushion). Back covers CA / U / R / CM. Mounting LB / FA / SDB / TC.
Where the Airtac MICJ Adjustable Mini Cylinder MICJ16X125-10 Is Used
Light Divert Gate
Operates a lightweight routing flap on a packaging line; the adjustable air cushion absorbs the impact of fast 125 mm strokes to prevent flap bounce.
Is the Airtac MICJ Adjustable Mini Cylinder MICJ16X125-10 the Right Cylinder?
For lighter duties, the MIJ bumper-only series is the next step down, as the cushioned MICJ line starts at this 16 mm bore. This model excels in fast set-position moves where the 10 mm extend adjuster and needle-set cushion prevent end-of-stroke banging.
The stop screw sets the end position but is not a mid-stroke lock; the piston will drift on air loss. Use an external rod lock or pilot check valve to hold a suspended load. Mount via LB foot, FA flange or TC trunnion, as the SDB pivot-block is not offered on adjustable-stroke variants.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G)
- ✓ Magnet (-S) for sensors?
- ✓ Back cover (CA/U/R/CM) & mount (LB/FA/SDB/TC)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check Use correct back cover (CA/U/R/CM) & mount (LB/FA/SDB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac MICJ Adjustable Mini Cylinder MICJ16X125-10 FAQ
This 16 mm bore cylinder uses an M5×0.8 port.
An external screw shortens the extend stroke by up to 10 mm, giving a usable forward range of 115-125 mm; retract remains full. The adjustable air cushion at both ends decelerates the piston near the ends to absorb high-speed shock. This SKU has no magnet, so it cannot take sensors.
