Airtac MICJ Adjustable Mini Cylinder MICJ16X125-100
The AirTAC MICJ Adjustable Mini Cylinder MICJ16X125-100 is a genuine double acting, double rod, adjustable stroke + cushion round-body mini air cylinder with a Ø16mm bore and 125mm stroke, M5×0.8 air ports and a stainless-steel barrel and rod for mildly corrosive environments. Its ISO 6432 mounting interface fits standard ISO 6432 mini-cylinder mounting interfaces.
- BoreØ16 mm
- Stroke125 mm
- Port sizeM5×0.8
- Acting typeDouble acting, double rod, adjustable stroke + cushion
- Rod threadM6×1.0
- CushionVariable air cushion, both ends
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MICJ Adjustable Mini Cylinder MICJ16X125-100
Trim the forward stop by up to 100 mm on site without swapping cylinders. This AirTAC MICJ16X125-100 is a double-acting, round-body stainless-steel mini cylinder with a variable air cushion at both ends, letting you set the extend position and soak up high-speed shock simultaneously.
Built to the ISO 6432 mounting interface, it drops into standard mini brackets and uses an M5×0.8 port with an M6x1.0 male rod thread. This SKU lacks a magnet, so it cannot take CMSG/DMSG/EMSG sensors.
Airtac MICJ Adjustable Mini Cylinder MICJ16X125-100 Technical Specifications
| Model | Airtac MICJ Adjustable Mini Cylinder MICJ16X125-100 |
|---|---|
| Series | MICJ ISO 6432 mini cylinder |
| Bore size | Ø16 mm |
| Stroke | 125 mm |
| Acting type | Double acting, double rod, adjustable stroke + cushion |
| Port size | M5×0.8 |
| Rod thread | M6×1.0 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Variable air cushion, both ends |
| Max standard stroke | Up to 500 mm |
Specifications follow the official AirTAC MI/MIC (ISO 6432) datasheet. Barrel & rod: stainless steel (round-body, riveted construction). Thread options: PT (blank) / G.
Theoretical Output Force (Ø16mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 86 N |
| 0.7 MPa | 121 N |
| Max (@1.0 MPa) | 18 kgf |
MIJ / MICJ are double-rod: the rear rod that carries the stroke adjuster exits the rear cover, so both piston faces lose rod area. The rod-side (annular) area is used for both directions (conservative).
Model Code: Airtac MICJ Adjustable Mini Cylinder MICJ16X125-100
| MICJ | ISO 6432 round-body mini cylinder (adjustable-stroke, variable cushion). |
|---|---|
| 16 | Bore size in mm. |
| ×125 | Stroke length in mm. |
| -100 | Adjustable stroke window (mm the extend stroke can be shortened on site). |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
MI-family variants: MI / MIC (double acting ±cushion), MSI / MTI (single acting push / pull), MID / MICD (double rod ±cushion), MIJ / MICJ (double rod, adjustable stroke ±cushion). Back covers CA / U / R / CM. Mounting LB / FA / SDB / TC.
Where the Airtac MICJ Adjustable Mini Cylinder MICJ16X125-100 Is Used
Adjustable Stop Gauging
Dial in the exact 25 to 125 mm extend position for a gauging probe, using the 100 mm adjustment screw to set the forward stop without swapping hardware.
Washdown Test Fixture
The stainless barrel and rod resist mild corrosion in damp test cells, while the ISO 6432 dimensions fit standard mini clevises.
Is the Airtac MICJ Adjustable Mini Cylinder MICJ16X125-100 the Right Cylinder?
For lighter duties, the MIJ bumper-only series is the smaller option, whereas stepping up to the MICJ 20mm bore raises the 0.5 MPa push force to 157 N. The 100 mm extend adjustment window is ideal for fast set-position moves where you need to dial in the exact forward stop without machining spacers.
The external screw sets the end position but is not a mid-stroke lock; the piston will drift on air loss, so add an external rod lock or pilot check valve for held loads. Choose LB foot, FA flange, or TC trunnion mounts, noting that SDB pivot-blocks are not available on this adjustable variant.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G)
- ✓ Magnet (-S) for sensors?
- ✓ Back cover (CA/U/R/CM) & mount (LB/FA/SDB/TC)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check Use correct back cover (CA/U/R/CM) & mount (LB/FA/SDB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac MICJ Adjustable Mini Cylinder MICJ16X125-100 FAQ
The theoretical maximum force is 20.5 kgf at 1.0 MPa, and the air port is M5×0.8.
An external screw shortens the extend stroke by up to 100 mm, while a needle valve adjusts the air cushion at both ends to absorb high-speed shock. The cushion only decelerates near stroke end and does not lock the piston; this non-magnet SKU cannot take sensors, and the -S variant is required for CMSG/DMSG/EMSG switches.
