Airtac MICJ Adjustable Mini Cylinder MICJ16X125-10S
The AirTAC MICJ Adjustable Mini Cylinder MICJ16X125-10S is a genuine double acting, double rod, adjustable stroke + cushion round-body mini air cylinder with a Ø16mm bore and 125mm stroke, M5×0.8 air ports and a stainless-steel barrel and rod for mildly corrosive environments. Its ISO 6432 mounting interface fits standard ISO 6432 mini-cylinder mounting interfaces.
- BoreØ16 mm
- Stroke125 mm
- Port sizeM5×0.8
- Acting typeDouble acting, double rod, adjustable stroke + cushion
- Rod threadM6×1.0
- CushionVariable air cushion, both ends
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MICJ Adjustable Mini Cylinder MICJ16X125-10S
Dial in the forward stop on-site without swapping hardware: this AirTAC MICJ16X125-10S round-body mini cylinder uses an external screw to shorten the extend stroke by up to 10 mm (usable forward travel 115-125 mm), while a needle-set adjustable air cushion at both ends soaks up high-speed shock. The stainless-steel riveted barrel and Ø6 mm piston rod resist mild corrosion and washdown. A built-in magnet (-S) supports CMSG, DMSG and EMSG position switches.
The stop screw sets the end position but is not a mid-stroke lock; the piston drifts on air loss, so add an external rod lock or pilot check valve to hold a suspended load.
Airtac MICJ Adjustable Mini Cylinder MICJ16X125-10S Technical Specifications
| Model | Airtac MICJ Adjustable Mini Cylinder MICJ16X125-10S |
|---|---|
| Series | MICJ ISO 6432 mini cylinder |
| Bore size | Ø16 mm |
| Stroke | 125 mm |
| Acting type | Double acting, double rod, adjustable stroke + cushion |
| Port size | M5×0.8 |
| Rod thread | M6×1.0 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Variable air cushion, both ends |
| Max standard stroke | Up to 500 mm |
Specifications follow the official AirTAC MI/MIC (ISO 6432) datasheet. Barrel & rod: stainless steel (round-body, riveted construction). Thread options: PT (blank) / G.
Theoretical Output Force (Ø16mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 86 N |
| 0.7 MPa | 121 N |
| Max (@1.0 MPa) | 18 kgf |
MIJ / MICJ are double-rod: the rear rod that carries the stroke adjuster exits the rear cover, so both piston faces lose rod area. The rod-side (annular) area is used for both directions (conservative).
Model Code: Airtac MICJ Adjustable Mini Cylinder MICJ16X125-10S
| MICJ | ISO 6432 round-body mini cylinder (adjustable-stroke, variable cushion). |
|---|---|
| 16 | Bore size in mm. |
| ×125 | Stroke length in mm. |
| -10 | Adjustable stroke window (mm the extend stroke can be shortened on site). |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
MI-family variants: MI / MIC (double acting ±cushion), MSI / MTI (single acting push / pull), MID / MICD (double rod ±cushion), MIJ / MICJ (double rod, adjustable stroke ±cushion). Back covers CA / U / R / CM. Mounting LB / FA / SDB / TC.
Where the Airtac MICJ Adjustable Mini Cylinder MICJ16X125-10S Is Used
Flap Tucking
Tucks carton flaps on a packing line; the adjustable forward stop lets you tune the 115-125 mm reach for different box sizes without remounting the cylinder.
Sample Diverting
Moves light test tubes or vials into a sensing station, relying on the 5.1 kg vertical lift capacity and the built-in magnet for DMSG switch confirmation.
Is the Airtac MICJ Adjustable Mini Cylinder MICJ16X125-10S the Right Cylinder?
Size both ways against the real thrust: stepping up to the Ø20 bore raises push to 157 N at 0.5 MPa, while dropping to a smaller Ø8/10/12 mini loses the cushion feature entirely (the smaller MIJ bumper type is the only adjustable option there).
The combination of the 10 mm extend trim and dual adjustable cushions shines in high-speed cycling where you must tune the landing without changing the mount. It uses the ISO 6432 mounting interface for standard mini brackets (LB, FA, TC; no SDB block on this adjustable variant). Because this SKU includes the -S magnet, you can fit CMSG/DMSG/EMSG sensors directly; a non-S SKU cannot take a sensor.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G)
- ✓ Magnet (-S) for sensors?
- ✓ Back cover (CA/U/R/CM) & mount (LB/FA/SDB/TC)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check Use correct back cover (CA/U/R/CM) & mount (LB/FA/SDB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac MICJ Adjustable Mini Cylinder MICJ16X125-10S FAQ
This 16 mm bore cylinder has an M5×0.8 air port.
An external screw shortens the extend stroke by up to 10 mm on-site (retract remains full). Needle valves adjust the air cushion at both ends to decelerate the piston near stroke end. The -S suffix means it has a built-in magnet for CMSG/DMSG/EMSG sensors. The stop screw and cushion only manage end-of-stroke motion; they do not lock or hold the load mid-stroke.
