Airtac MICJ Adjustable Mini Cylinder MICJ16X125-40
The AirTAC MICJ Adjustable Mini Cylinder MICJ16X125-40 is a genuine double acting, double rod, adjustable stroke + cushion round-body mini air cylinder with a Ø16mm bore and 125mm stroke, M5×0.8 air ports and a stainless-steel barrel and rod for mildly corrosive environments. Its ISO 6432 mounting interface fits standard ISO 6432 mini-cylinder mounting interfaces.
- BoreØ16 mm
- Stroke125 mm
- Port sizeM5×0.8
- Acting typeDouble acting, double rod, adjustable stroke + cushion
- Rod threadM6×1.0
- CushionVariable air cushion, both ends
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MICJ Adjustable Mini Cylinder MICJ16X125-40
Dial in a precise forward stop on-site with the AirTAC MICJ16X125-40, a 16 mm bore stainless-steel round-body mini cylinder. An external stop screw shortens the extend stroke by up to 40 mm, giving a usable forward range of 85-125 mm, while a needle-adjustable air cushion at both ends absorbs high-speed shock. It conforms to the ISO 6432 mounting interface for straightforward bracket interchange.
The stainless barrel and piston rod supply mild washdown resistance. This SKU lacks a magnet, so it cannot host CMSG/DMSG/EMSG sensors; add the -S variant for position detection. The M5×0.8 port and M6x1.0 male rod thread match standard mini fittings.
Airtac MICJ Adjustable Mini Cylinder MICJ16X125-40 Technical Specifications
| Model | Airtac MICJ Adjustable Mini Cylinder MICJ16X125-40 |
|---|---|
| Series | MICJ ISO 6432 mini cylinder |
| Bore size | Ø16 mm |
| Stroke | 125 mm |
| Acting type | Double acting, double rod, adjustable stroke + cushion |
| Port size | M5×0.8 |
| Rod thread | M6×1.0 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Variable air cushion, both ends |
| Max standard stroke | Up to 500 mm |
Specifications follow the official AirTAC MI/MIC (ISO 6432) datasheet. Barrel & rod: stainless steel (round-body, riveted construction). Thread options: PT (blank) / G.
Theoretical Output Force (Ø16mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 86 N |
| 0.7 MPa | 121 N |
| Max (@1.0 MPa) | 18 kgf |
MIJ / MICJ are double-rod: the rear rod that carries the stroke adjuster exits the rear cover, so both piston faces lose rod area. The rod-side (annular) area is used for both directions (conservative).
Model Code: Airtac MICJ Adjustable Mini Cylinder MICJ16X125-40
| MICJ | ISO 6432 round-body mini cylinder (adjustable-stroke, variable cushion). |
|---|---|
| 16 | Bore size in mm. |
| ×125 | Stroke length in mm. |
| -40 | Adjustable stroke window (mm the extend stroke can be shortened on site). |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
MI-family variants: MI / MIC (double acting ±cushion), MSI / MTI (single acting push / pull), MID / MICD (double rod ±cushion), MIJ / MICJ (double rod, adjustable stroke ±cushion). Back covers CA / U / R / CM. Mounting LB / FA / SDB / TC.
Where the Airtac MICJ Adjustable Mini Cylinder MICJ16X125-40 Is Used
Film Feed Tensioner
Uses the adjustable air cushion to decelerate the 125 mm stroke at high speed, preventing web tears on packaging machinery.
Lab Dispense Head
Sets a precise forward position for a 5.1 kg liquid dispensing head, relying on the stainless body for mild corrosion resistance.
Is the Airtac MICJ Adjustable Mini Cylinder MICJ16X125-40 the Right Cylinder?
The external stop screw and dual cushions shine in fast set-position tasks where you must tune the impact without swapping hardware. Remember the stop screw sets the end position but is not a mid-stroke lock; the piston will drift on air loss, so fit an external rod lock or pilot check valve to hold a suspended load.
Mount using LB foot, FA flange or TC trunnion brackets (SDB pivot-block is not available on this adjustable-stroke build). Back covers include CA, U, R and CM. Because this specific code has no -S suffix, it cannot accept magnetic sensors.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G)
- ✓ Magnet (-S) for sensors?
- ✓ Back cover (CA/U/R/CM) & mount (LB/FA/SDB/TC)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check Use correct back cover (CA/U/R/CM) & mount (LB/FA/SDB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac MICJ Adjustable Mini Cylinder MICJ16X125-40 FAQ
At 0.5 MPa it pushes 100.5 N and pulls 86.4 N. At 0.7 MPa it pushes 140.7 N and pulls 120.9 N. The theoretical max force is 20.5 kgf at 1.0 MPa. This 16 mm bore cylinder uses an M5×0.8 port.
An external screw shortens the extend stroke by up to 40 mm (retract stays full), while needle valves tune the air cushion at both ends to absorb high-speed shock. This SKU has no magnet and cannot take CMSG/DMSG/EMSG sensors; choose the -S variant for sensing. The cushion only decelerates near stroke end and is not a lock.
