Airtac MTD Multi-position Locking Cylinder MTD10X20S
The AirTAC MTD Multi-position Locking Cylinder MTD10X20S is a genuine MD multi-mount cylinder (single acting, pull type), 10 mm bore. Its compact square body fixes from six directions and mounts side by side to save space. It delivers about 9.5 N of pull force at 0.5 MPa. A bumper cushions the impact.
- TypeMulti-mount, single acting, pull type
- SeriesMD (standard)
- Bore10 mm
- Pull thrust @0.5 MPa9.5 N
- Operating pressure0.2 - 1.0 MPa (28 - 145 psi)
- Port sizeM5x0.8
- CushionBumper
- MagnetWith magnet (sensor-ready)
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MTD Multi-position Locking Cylinder MTD10X20S
The AirTAC MTD multi-mount cylinder is a compact square-body actuator that can be fixed from six directions - front, back, left, right, top and bottom - and mounted side by side to save space. This MTD10X20S is the single-acting, pull-type variant in a 10mm bore with a 20mm stroke: air power draws the rod in over the full short travel, fitting retract-type clamp, stopper and positioning work in dense panel layouts. Cushioning is a bumper, magnetic-switch slots run around the body, and guide precision is high with no added lubricant required. The trailing S means this SKU is supplied with the magnet, ready to work with magnetic switches.
This is a genuine AirTAC part from the MD family, the standard multi-mount series - rod rotation is not restricted here (that is the MK no-rotating family's role). It runs on air filtered to 40 um at 0.2-1.0 MPa (28-145 psi), from -20 to 70 C (up to 150 C only with the optional high-temperature seal material), at 50-500 mm/s. We confirm dimensions and sizing from the datasheet on request.
Airtac MTD Multi-position Locking Cylinder MTD10X20S Technical Specifications
| Model | Airtac MTD Multi-position Locking Cylinder MTD10X20S |
|---|---|
| Type | Multi-mount cylinder, single acting, pull type |
| Series | MD (standard) |
| Bore | 10 mm |
| Pull thrust @0.5 MPa | 9.5 N |
| Port size | M5x0.8 (PT thread) |
| Magnet | With magnet (S) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.2 - 1.0 MPa (28 - 145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s |
| Cushion | Bumper |
| Mounting | Fix from 6 directions; mountable side by side |
Specifications follow the official AirTAC MD/MK multi-mount data. The front cover and piston are short, so avoid an over-long stroke. An optional high-temperature seal material extends the range to 0 to 150 C. Overall dimensions vary per stroke and allowable side-load is published as curves — ask us and we confirm from the datasheet.
How to choose
Match the bore to the force needed: 10mm is the compact mid-size of the range. As this is a single-acting pull type, confirm the pull-side thrust for this bore from the datasheet - single-acting figures differ by side, the push side is always the higher, and the two sides must not be mixed. MD is the standard family (rotation allowed); pick MK where the rod must not rotate. Acting options are double acting (MD), single-acting push (MSD), single-acting pull (MTD, this model), double rod (MDD) and adjustable-stroke (MDJ). Single-acting strokes run up to 20mm, so this stroke sits at the top of the range - the short cover cautions against anything longer. The S suffix here means the magnet is included; ports are M5x0.8 with PT thread, with G as the alternative. Route side-load questions to us.
Applications
Vertical retract clamp
Pull a small clamp or lifting finger upward out of the way inside a compact machine head, with the cylinder fixed from the top or bottom face.
Machine-tool stopper
Retract a stopper pin that halts a sliding fixture or pallet on a machining line, sensing end position with a switch in the body slot.
Pick-and-place release
Draw a small gripper or part carrier back from a nest on a compact pick-and-place module, stacking several cylinders side by side under the plate.
FAQ
What does the acting type of the MTD mean in practice?
MTD is the single-acting, pull-type variant of the MD multi-mount family: air power does the pulling stroke, in contrast to the push-type MSD. Operating pressure is 0.2-1.0 MPa (28-145 psi) at this 10mm bore and speed is 50-500 mm/s. For the exact pull-side thrust figure at your working pressure, confirm from the datasheet - single-acting push-side figures are higher and should not be substituted.
Where do I find dimensions and side-load limits for this cylinder?
Overall dimensions depend on the stroke and mount orientation, and side-load capacity is not published as a simple number here, so both should be confirmed from the datasheet - we can send it and help with sizing on request. What is fixed by design is the six-direction mounting and the side-by-side layout that saves panel space.
