Airtac RMH Magnetic Coupling Rodless Cylinder RMH16X400S
$317.75
Regular price
$325.25
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
RMH16X400S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Magnetic coupling rodless cylinder design eliminates mechanical connection between piston and slider, delivering exceptional sealing performance;
2. Piston motion is transmitted to external slider via magnetic coupling force, eliminating piston rod requirements. Requires 30% less installation space than standard cylinders while achieving 50% longer stroke lengths;
3. Integrated adjustable cushioning with fixed buffer devices at both ends ensures smooth direction reversal with near-zero impact, effectively preventing mechanical wear. Optional external hydraulic shock absorbers available for enhanced damping performance;
4. Isolated piston chamber design creates physical separation from slider mechanism, blocking particulate contamination to extend operational lifespan;
5. Precision-guided rail system ensures ±0.1mm repeat positioning accuracy with anti-rotation stability, supporting radial loads up to 650N.
Category: Rodless Cylinders | Brand: Airtac | Series: RMH
Installation notes:
1. Maintain horizontal mounting (±3° tolerance) for optimal magnetic coupling efficiency
2. Use M5×0.8 mounting screws with 0.4–0.6Nm torque
3. Allow 5mm clearance below slider for magnetic sensor installation
4. Lubricate guide rail monthly with ISO VG32 turbine oil
Avoid side-load exceeding 8N or moment load over 0.5Nm.
Always align external load center with cylinder axis (±0.3mm).
2. Piston motion is transmitted to external slider via magnetic coupling force, eliminating piston rod requirements. Requires 30% less installation space than standard cylinders while achieving 50% longer stroke lengths;
3. Integrated adjustable cushioning with fixed buffer devices at both ends ensures smooth direction reversal with near-zero impact, effectively preventing mechanical wear. Optional external hydraulic shock absorbers available for enhanced damping performance;
4. Isolated piston chamber design creates physical separation from slider mechanism, blocking particulate contamination to extend operational lifespan;
5. Precision-guided rail system ensures ±0.1mm repeat positioning accuracy with anti-rotation stability, supporting radial loads up to 650N.
Category: Rodless Cylinders | Brand: Airtac | Series: RMH
AirTAC RMH Magnetic Coupled Rodless Cylinder RMH16X400S Specifications
- Model: RMH16X400S
- Type: Magnetic coupled rodless cylinder (non-rotating)
- Bore size: 16mm
- Stroke length: 400mm ±1mm
- Operating pressure: 0.1–0.8 MPa
- Operating temperature: -10℃ to 70℃
- Cushion type: Adjustable pneumatic cushion
- Repeat positioning accuracy: ±0.5mm
- Max speed: 1.5 m/s (with cushion)
- Seal material: NBR (nitrile rubber)
- Port size: Rc1/8 (PT1/8 equivalent)
- Weight: 1.2kg ±5% (excluding accessories)
- Dimensions: 450mm(L) × 36mm(W) × 42mm(H)
- Slider material: Anodized aluminum alloy
- Magnetic field strength: ≤30mT (safe for sensors)
- Lubrication: Pre-lubricated (relubrication interval ≥2000km)
High-precision rodless actuator using magnetic coupling technology to eliminate external seals. Features integrated T-slot mounting (4×M5) and wear-resistant guide bearings. The dual-magnet system prevents decoupling at maximum load, with IP54-rated dust protection. Requires 40μm filtered compressed air and periodic wiper seal maintenance.
Typical Applications:
- Linear transfer systems in cleanroom environments
- Cartesian robot Z-axis positioning
- Glass panel handling equipment
- Pharmaceutical blister packaging machines
- Semiconductor wafer transport mechanisms
Installation notes:1. Maintain horizontal mounting (±3° tolerance) for optimal magnetic coupling efficiency
2. Use M5×0.8 mounting screws with 0.4–0.6Nm torque
3. Allow 5mm clearance below slider for magnetic sensor installation
4. Lubricate guide rail monthly with ISO VG32 turbine oil
Avoid side-load exceeding 8N or moment load over 0.5Nm.Always align external load center with cylinder axis (±0.3mm).
| Property | Property Value |
|---|---|
| sku | RMH16X400S |
| Safety Holding Force N | Bore 140mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-400mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Fixed Cushion |
| Bore Diameter | 16mm |
| Stroke | <400mm> |
