Airtac RMH Magnetic Coupling Rodless Cylinder RMH16X500S
$346.59
Regular price
$354.09
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
RMH16X500S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Magnetic coupling rodless cylinder design eliminates mechanical connection between piston and slider, delivering exceptional sealing performance;
2. Piston motion is transmitted to external slider via magnetic coupling force, eliminating piston rod requirements. Requires 30% less installation space than standard cylinders while achieving 50% longer stroke lengths;
3. Integrated adjustable cushioning with fixed buffer devices at both ends ensures smooth direction reversal with near-zero impact, effectively preventing mechanical wear. Optional external hydraulic shock absorbers available for enhanced damping performance;
4. Isolated piston chamber design creates physical separation from slider mechanism, blocking particulate contamination to extend operational lifespan;
5. Precision-guided rail system ensures ±0.1mm repeat positioning accuracy with anti-rotation stability, supporting radial loads up to 650N.
Category: Rodless Cylinders | Brand: Airtac | Series: RMH
Installation guidelines:
Maintain ≤0.1mm/m alignment tolerance during mounting.
Use only non-magnetic mounting brackets to prevent magnetic interference.
Apply silicone-free lubricant (ISO VG32) during maintenance.
Maximum side load: 30N at mid-stroke.
2. Piston motion is transmitted to external slider via magnetic coupling force, eliminating piston rod requirements. Requires 30% less installation space than standard cylinders while achieving 50% longer stroke lengths;
3. Integrated adjustable cushioning with fixed buffer devices at both ends ensures smooth direction reversal with near-zero impact, effectively preventing mechanical wear. Optional external hydraulic shock absorbers available for enhanced damping performance;
4. Isolated piston chamber design creates physical separation from slider mechanism, blocking particulate contamination to extend operational lifespan;
5. Precision-guided rail system ensures ±0.1mm repeat positioning accuracy with anti-rotation stability, supporting radial loads up to 650N.
Category: Rodless Cylinders | Brand: Airtac | Series: RMH
AirTAC RMH Magnetic Coupled Rodless Cylinder RMH16X500S Specifications
- Model: RMH16X500S
- Bore size: 16mm
- Stroke: 500mm (±0.5mm tolerance)
- Operating pressure: 0.05-1.0 MPa
- Max speed: 0.1-2.0 m/s
- Cushion type: Fixed rubber buffer (both ends)
- Mounting: Female thread (M6x1.0) base mounting
- Seal material: HNBR (Hydrogenated Nitrile) with wear-resistant ring
- Ambient temperature: -20℃ to 80℃
- Lubrication: Pre-lubricated (Relubrication interval: 2000km travel)
- Magnetic coupling force: ≥180N (at 0.5MPa)
- Repeat positioning accuracy: ±0.2mm
- Weight: 1.25kg (excluding accessories)
- Dimensions: 584mm(L) x 28mm(W) x 38mm(H)
- Port size: M5x0.8 (Standard) / NPT1/8 (Optional)
- Protection class: IP54 (Dust protected & water splashed)
Advanced rodless cylinder utilizing magnetic coupling technology to eliminate external leakage points. Features anodized aluminum alloy body with chrome-plated stainless steel guide rail. Integrated T-slot along the carriage enables direct load mounting. Optimized for high duty cycles - rated for 10,000km travel life at 0.5MPa with proper maintenance.
Typical Applications:
- Precision linear motion in cleanroom environments (semiconductor handling)
- Vertical lifting mechanisms in packaging machinery
- Automated guided vehicle (AGV) door opening systems
- High-speed sorting equipment in logistics centers
- Plastic injection molding machine part extraction
Installation guidelines:
Maintain ≤0.1mm/m alignment tolerance during mounting.
Use only non-magnetic mounting brackets to prevent magnetic interference.
Apply silicone-free lubricant (ISO VG32) during maintenance.
Maximum side load: 30N at mid-stroke.
| Property | Property Value |
|---|---|
| sku | RMH16X500S |
| Safety Holding Force N | Bore 140mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-400mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Fixed Cushion |
| Bore Diameter | 16mm |
| Stroke | 500mm |
