Airtac S3PM Mushroom Head Push Button Mechanical Valve S3PM-06-B
2. The S3PF, S3PM, S3PP, S3PL, S3Y, S3HS, S3C, and S3D series feature manual operation with diverse actuator head configurations to accommodate varied operational conditions.
3. Poppet structure ensures superior sealing performance, smooth directional switching, and maintenance-free oil-free lubrication.
4. Multi-position mounting capability for flexible installation and user convenience.
5. S3C, S3D, S3Y, S3R, and S3L series employ metallic actuator heads for enhanced durability, reliability, and operational stability.
Category: Mechanical Valves | Brand: Airtac | Series: S3PM Mushroom Head Push Button Style
AirTAC S3PM-06-B Mushroom Head Push Button Mechanical Valve Specifications
- Model: S3PM-06-B
- Type: 3/2-way mechanical valve (manual reset)
- Operation: Mushroom head emergency stop design
- Port size: PT1/4 (G1/4 equivalent)
- Thread standard: BSPP (parallel thread)
- Operating pressure: 0.1–1.0 MPa
- Max flow rate: 850 L/min (ANR)
- Actuation force: 30–50N
- Body material: Nickel-plated brass
- Seal material: Heat-resistant NBR
- Temperature range: -10℃ to 80℃
- Weight: 220g ±5%
- Dimensions: 54mm(D) × 54mm(H) × 42mm(W)
- Mounting: Panel mounting (22mm cutout)
- Protection rating: IP67 (dust/water resistant)
- Mechanical life: ≥500,000 cycles
Emergency safety valve with oversized 35mm mushroom head for instant system shutdown. Features positive-lock mechanism requiring manual twist-release for reset. The dual-color indicator ring (red/yellow) provides visible status confirmation. Optimized for high-vibration environments with stainless steel spring and anti-loosening locknut.
- Production line emergency stop stations
- Injection molding machine safety systems
- CNC equipment panic switches
- Robotic cell safety interlocks
- Hydraulic press emergency release
Installation note:
Requires 1.5-2Nm torque for secure mounting. For vertical installations,
use included splash guard (P/N: SG-04). Test monthly by performing full
depression and 45° rotation check.
| Property | Property Value |
|---|---|
| sku | S3PM-06-B |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
