Airtac SAI160 Standard Cylinder SAI160AX120S
The AirTAC SAI160 Standard Cylinder SAI160AX120S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø160mm bore and 120mm stroke, G3/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ160 mm
- Stroke120 mm
- Port sizeG3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 50 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAI160 Standard Cylinder SAI160AX120S
The AirTAC SAI160X120-S is a double-acting ISO 15552 profile cylinder engineered for heavy-duty operations, delivering a substantial push force of 14074 N at 0.7 MPa. Its 120 mm stroke provides the precise linear movement required for high-tonnage pressing, clamping, and lifting tasks. As a genuine AirTac component, it ensures reliable performance in rigorous industrial environments.
This specific configuration includes a SUS420J2 stainless steel piston rod (material code A) for enhanced corrosion and wear resistance compared to standard carbon steel. Equipped with a built-in magnet (-S), it seamlessly integrates with CMSE and DMSE sensor switches housed in the dual-side grooves of its extruded aluminum barrel. Fluid control is managed via PT tapered port threads, and the cylinder incorporates adjustable air cushions at both ends to decelerate the massive 160 mm piston smoothly.
Airtac SAI160 Standard Cylinder SAI160AX120S Technical Specifications
| Model | Airtac SAI160 Standard Cylinder SAI160AX120S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø160 mm |
| Stroke | 120 mm |
| Acting type | Double acting |
| Port size | G3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 50 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø160mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 10053 N | 9425 N |
| 0.7 MPa | 14074 N | — |
| Max (@1.0 MPa) | 2050 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAI160 Standard Cylinder SAI160AX120S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 160 | Bore size in mm. |
| ×120 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAI160 Standard Cylinder SAI160AX120S Is Used
Heavy-Duty Stamping
Provides the 14074 N push force at 0.7 MPa necessary for forming, stamping, and riveting thick metal components in automated fabrication lines.
Injection Mold Clamping
Utilizes its 120 mm stroke and robust 160 mm profile barrel to secure heavy molds and dies, ensuring precise alignment during high-pressure manufacturing cycles.
Pallet Lifting
Lifts and positions fully loaded industrial pallets, relying on the SUS420J2 stainless steel rod to withstand harsh environments and high dynamic loads.
Is the Airtac SAI160 Standard Cylinder SAI160AX120S the Right Cylinder?
Selecting this 160 mm bore cylinder is ideal when your application demands extremely high thrust, such as replacing a 125 mm bore unit that only provides 8590 N push force at 0.7 MPa. If 14074 N is excessive for your system, stepping down to an 80 mm bore yields 3518 N at the same pressure, which may better suit lighter loads and conserve compressed air.
Because the 120 mm stroke is relatively short for this large bore, side-load stress on the rod bearing is minimized compared to longer strokes. However, remember that the standard SAI does not lock or hold position when air pressure is removed; the piston will drift. If your application requires dead-stop holding under zero pressure, specify the SAIL variant with an air-released lock or the BSAI bidirectional clamp-lock cylinder.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAI160 Standard Cylinder SAI160AX120S FAQ
At a standard operating pressure of 0.7 MPa, the SAI160X120-S generates a push force of 14074 N and a pull force of 9425 N. The maximum theoretical force at 1.0 MPa is 2050 kgf.
Yes, the SAI160X120-S is dimensionally interchangeable per ISO 15552. Its standardized mounting interface allows it to replace other ISO 15552 profile cylinders seamlessly, provided you match the PT port threads and mounting accessories.
