Airtac SAI160 Standard Cylinder SAI160AX135S
The AirTAC SAI160 Standard Cylinder SAI160AX135S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø160mm bore and 135mm stroke, G3/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ160 mm
- Stroke135 mm
- Port sizeG3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 50 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAI160 Standard Cylinder SAI160AX135S
The AirTAC SAI160X135-S is a double-acting ISO 15552 profile cylinder engineered for heavy-duty operations, delivering a robust push force of 14074 N at 0.7 MPa. With a 160 mm bore and 135 mm stroke, this tie-rod-less extruded aluminum barrel design provides a standardized mounting interface that is dimensionally interchangeable with other ISO 15552 actuators.
Equipped from the factory with a SUS420J2 stainless steel piston rod (material code A) and a built-in magnet (-S), this model seamlessly integrates with CMSE and DMSE series sensor switches via the dual-side grooves on the barrel. Fluid must be filtered air, operating reliably within the -20 to +70 C temperature range.
Airtac SAI160 Standard Cylinder SAI160AX135S Technical Specifications
| Model | Airtac SAI160 Standard Cylinder SAI160AX135S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø160 mm |
| Stroke | 135 mm |
| Acting type | Double acting |
| Port size | G3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 50 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø160mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 10053 N | 9425 N |
| 0.7 MPa | 14074 N | — |
| Max (@1.0 MPa) | 2050 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAI160 Standard Cylinder SAI160AX135S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 160 | Bore size in mm. |
| ×135 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAI160 Standard Cylinder SAI160AX135S Is Used
Heavy Metal Stamping
Provides the high clamping force necessary to hold large sheet metal blanks securely in place during heavy-duty stamping operations.
Large Press Demolding
Generates sufficient extend and retract force to safely eject heavy molded components from large industrial presses.
Automotive Assembly Jigs
Actuates massive welding fixtures and structural positioning jigs where high thrust and rigid ISO 15552 mounting are required.
Is the Airtac SAI160 Standard Cylinder SAI160AX135S the Right Cylinder?
If your application requires less force, stepping down to the 125 mm bore yields 8590 N of push force at 0.5 MPa, whereas the 200 mm bore provides a massive 21991 N at 0.7 MPa for higher capacity needs. For this 135 mm stroke, side-load bending on the rod bearing is minimal, but always verify guiding if operating near the 30-500 mm/s speed range limits.
This genuine AirTAC unit uses a PT tapered port thread and adjustable air cushions at both ends to decelerate the piston. Note that standard double-acting cylinders drift when air pressure is removed; if your workflow demands fail-safe load holding, specify the SAIL variant or an external rod lock.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAI160 Standard Cylinder SAI160AX135S FAQ
At 0.7 MPa, this 160 mm bore cylinder generates a push force of 14074 N and a pull force of 13274 N. The theoretical maximum force at 1.0 MPa is 2050 kgf.
Yes, the SAI160X135-S features a standard ISO 15552 mounting interface, making it dimensionally interchangeable with other profile cylinders of the same bore size.
Authorized Export Seller
Genuine AirTAC parts produced by AirTAC factory.
1-Year Warranty
Covers non-human-caused product damage.
Fast Dispatch
Standard models are processed and dispatched in 3-5 business days.
Fast Reply
Most inquiries answered within 7-8 hours.
Related AirTAC SAI Cylinders
Request a Quote for Airtac SAI160 Standard Cylinder SAI160AX135S
Send us the quantity and destination. We confirm price, stock and lead time — usually within 7-8 hours.
