Airtac SAI200 Standard Cylinder SAI200AX100
The AirTAC SAI200 Standard Cylinder SAI200AX100 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø200mm bore and 100mm stroke, G3/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ200 mm
- Stroke100 mm
- Port sizeG3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 50 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAI200 Standard Cylinder SAI200AX100
The AirTAC SAI200X100 is a double-acting ISO 15552 profile cylinder engineered for immense pushing and pulling tasks. Operating at 0.5 MPa, it generates a substantial 15708 N of push force and 15080 N of pull force. This 100 mm stroke variant is purpose-built for heavy-duty pressing, lifting, and clamping operations where high mass must be moved over a short, controlled distance.
Reflecting its industrial-grade design, this configuration incorporates a SUS420J2 stainless steel piston rod for superior corrosion and wear resistance. Fluid supply is routed through PT tapered ports, and while this base unit lacks a magnet, the extruded aluminum barrel features dual sensor grooves for adding CMSE or DMSE switches when position feedback is required.
Airtac SAI200 Standard Cylinder SAI200AX100 Technical Specifications
| Model | Airtac SAI200 Standard Cylinder SAI200AX100 |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø200 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | G3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 50 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø200mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 15708 N | 15080 N |
| 0.7 MPa | 21991 N | — |
| Max (@1.0 MPa) | 3204 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAI200 Standard Cylinder SAI200AX100
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 200 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAI200 Standard Cylinder SAI200AX100 Is Used
Heavy-Duty Stamping
Provides the robust 15708 N force required to form, stamp, and pierce thick metal components in automated fabrication lines.
Industrial Pressing
Ideal for high-tonnage pressing and riveting applications where short, stable 100 mm strokes must deliver consistent joining force.
Massive Payload Lifting
Excels at elevating and lowering heavy industrial molds or palletized goods, utilizing its 15080 N pull force to retract securely.
Is the Airtac SAI200 Standard Cylinder SAI200AX100 the Right Cylinder?
Selecting this 200 mm bore cylinder is appropriate when application thrust requirements exceed the 10053 N available from the 160 mm bore at 0.5 MPa. If the 15708 N output is excessive for your fixture, stepping down to the 160 mm option provides a more compact footprint. Because the stroke is 100 mm, side-load stress on the rod bearing is minimal, though external guides are always recommended for heavy payloads.
This model provides true ISO 15552 mounting interchangeability, allowing direct replacement for other standard profile cylinders of the same bore. Ensure your setup specifies the G3/4 port size, PT thread type, and appropriate mounting accessories like the TC trunnion or CA clevis. Note that the standard adjustable air cushions only decelerate the piston at stroke ends; if the system must hold a suspended load after air pressure is cut, integrate an external pilot check valve or utilize the BSAI clamp-lock variant.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAI200 Standard Cylinder SAI200AX100 FAQ
At an operating pressure of 0.5 MPa, this 200 mm bore cylinder provides 15708 N of push force and 15080 N of pull force. The maximum theoretical force at 1.0 MPa is 3204 kgf.
Yes, the SAI200X100 is dimensionally interchangeable per ISO 15552 standards. You can drop it into existing machinery designed for ISO 15552 profile cylinders, provided your porting matches the G3/4 size.
