Airtac SAI200 Standard Cylinder SAI200AX1000
The AirTAC Airtac SAI200 Standard Cylinder SAI200AX1000 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø200mm bore and 1000mm stroke, G3/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ200 mm
- Stroke1000 mm
- Port sizeG3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 50 mm
About the Airtac SAI200 Standard Cylinder SAI200AX1000
The AirTAC SAI200X1000 is a double-acting ISO 15552 profile cylinder engineered for heavy-duty motion tasks. It provides a substantial push force of 15708 N and a pull force of 15080 N at 0.5 MPa. The 1000 mm stroke makes it well-suited for moving massive loads across long linear distances in large-scale fabrication environments.
This specific configuration features a SUS420J2 stainless steel piston rod (material code A) for superior corrosion resistance compared to standard carbon steel. It uses PT tapered port threads and lacks a standard magnet, meaning position sensing via CMSE or DMSE switches requires a custom -S modification.
Airtac SAI200 Standard Cylinder SAI200AX1000 Technical Specifications
| Model | Airtac SAI200 Standard Cylinder SAI200AX1000 |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø200 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | G3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 50 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø200mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 15708 N | 15080 N |
| 0.7 MPa | 21991 N | — |
| Max (@1.0 MPa) | 3204 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAI200 Standard Cylinder SAI200AX1000
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 200 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAI200 Standard Cylinder SAI200AX1000 Is Used
Heavy Metal Pressing
Drives large presses and stamping stations requiring up to 3204 kgf of theoretical force at 1.0 MPa.
Large Mold Handling
Actuates 1000 mm linear transitions for moving heavy injection molds into and out of processing machines.
Bulk Material Diversion
Powers heavy-duty diverter arms on large-scale conveyor lines handling bulk raw materials.
Is the Airtac SAI200 Standard Cylinder SAI200AX1000 the Right Cylinder?
Choose this 200 mm bore when your application demands extreme thrust that smaller bores cannot provide. If 15708 N at 0.5 MPa is excessive, stepping down to the 160 mm bore yields 10053 N of push force. At a 1000 mm stroke, the extended rod is highly susceptible to bending under side loads. Utilizing an external guide rail or a fully guided cylinder is strongly recommended to prevent premature rod-bearing wear.
This model is dimensionally interchangeable per ISO 15552, serving as a drop-in replacement for other ISO 15552 profile cylinders. It features a G3/4 port, a 50 mm cushion length, and a max standard stroke of 1500 mm. For applications requiring intermediate position holding without sustained air pressure, consider the SAIL locking variant or an external rod lock.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAI200 Standard Cylinder SAI200AX1000 FAQ
At an operating pressure of 0.5 MPa, this 200 mm bore cylinder generates 15708 N of push force and 15080 N of pull force. At 0.7 MPa, the push force increases to 21991 N.
Yes, the SAI200X1000 is a genuine ISO 15552 profile cylinder, making its mounting interface dimensionally interchangeable with other ISO 15552 compliant cylinders.
